528150-YTG-G-1210
Johnson Controls Unitary Products 87
75°F 85°F
2125
72 42.8 6.3 ----- 37.6 6.4 -----
67 35.4 6.51.61.51.41.2- 28.6 6.8 -----
62 31.9 6.24.44.34.24.14.024.7 6.5 -----
2550
72 50.9 6.2 ----- 48.3 6.4 -----
67 42.1 6.4 6.2 5.4 4.7 3.9 - 37.3 6.8 3.3 2.9 2.5 2.0 -
62 38.0 6.1 16.6 15.8 15.0 14.3 13.5 32.5 6.5 13.0 12.5 12.1 11.6 11.2
57 29.4 6.1 16.6 15.8 15.0 14.3 13.5 22.5 6.4 10.6 10.1 9.7 9.3 8.8
2975
72 59.1 6.2 ----- 58.9 6.3 -----
67 48.9 6.4 10.8 9.4 8.0 6.6 - 46.0 6.7 7.9 6.8 5.7 4.6 -
62 44.0 6.1 28.7 27.3 25.9 24.5 23.1 40.2 6.4 26.6 25.5 24.4 23.3 22.2
57 34.1 6.0 27.7 27.3 25.9 24.5 23.1 28.4 6.4 22.4 22.2 21.1 20.0 19.0
3400
72 67.2 6.2 ----- 69.6 6.3 -----
67 55.6 6.3 15.4 13.3 11.3 9.2 - 54.7 6.7 12.5 10.7 9.0 7.3 -
62 50.1 6.0 40.9 38.8 36.8 34.7 32.6 48.0 6.4 40.2 38.5 36.7 35.0 33.3
57 38.8 6.0 38.8 38.8 36.8 34.7 32.6 34.3 6.3 34.3 34.3 32.6 30.8 29.1
3825
72 68.6 6.1 ----- 69.7 6.2 -----
67 56.7 6.3 19.7 17.0 14.4 11.7 - 54.6 6.6 17.2 14.9 12.5 10.2 -
62 51.1 6.0 46.5 45.5 42.8 40.1 37.5 47.9 6.3 45.3 45.4 43.1 40.7 38.3
57 39.6 5.9 39.6 39.6 36.9 34.3 31.6 34.0 6.3 34.0 34.0 31.6 29.3 26.9
4250
72 69.9 6.1 ----- 69.8 6.2 -----
67 57.8 6.3 24.0 20.8 17.5 14.2 - 54.5 6.6 22.0 19.0 16.0 13.1 -
62 52.1 5.9 52.1 52.1 48.8 45.6 42.3 47.7 6.3 47.7 47.7 47.7 46.4 43.4
57 40.4 5.9 40.4 40.4 37.1 33.9 30.6 33.7 6.2 33.7 33.7 30.7 27.8 24.8
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
ZR102 (8.5 Ton) Reheat (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
85 80 75 70 65 85 80 75 70 65
