528150-YTG-G-1210
50 Johnson Controls Unitary Products
115°F 125°F
3125
77 158.4 14.6 65.6 53.5 40.6 - - - 147.6 16.1 60.0 50.8 38.1 - - -
72 144.6 14.5 88.2 75.4 62.5 49.6 - - 134.2 16.0 84.9 72.2 59.5 46.8 - -
67 130.9 14.3 110.9 97.3 84.4 71.5 58.7 - 120.9 15.8 107.4 93.6 80.9 68.2 55.5 -
62 120.5 14.0 120.5 120.5 104.7 91.9 79.0 66.1 112.3 15.6 112.3 112.3 100.7 87.9 75.2 62.5
3750
77 162.2 14.7 73.1 58.6 44.1 - - - 150.8 16.1 69.9 55.6 41.3 - - -
72 148.1 14.5 96.9 82.4 67.9 53.3 - - 137.2 16.0 93.0 78.7 64.5 50.2 - -
67 134.0 14.3 120.6 106.1 91.6 77.1 62.6 - 123.5 15.8 116.2 101.9 87.6 73.4 59.1 -
62 123.3 14.1 123.3 123.3 113.7 99.2 84.7 70.2 114.8 15.6 114.8 114.8 109.0 94.7 80.5 66.2
57 121.8 14.1 121.8 121.8 110.3 95.8 81.2 66.7 112.1 15.6 112.1 112.1 102.2 88.0 73.7 59.4
4375
77 165.9 14.7 80.6 63.7 47.6 - - - 154.1 16.1 79.7 60.3 44.5 - - -
72 151.5 14.5 105.5 89.4 73.2 57.1 - - 140.1 15.9 101.1 85.3 69.5 53.6 - -
67 137.1 14.3 130.4 115.0 98.9 82.7 66.6 - 126.2 15.8 125.0 110.2 94.4 78.6 62.7 -
62 126.2 14.1 126.2 126.2 122.7 106.5 90.4 74.2 117.2 15.5 117.2 117.2 117.2 101.6 85.7 69.9
57 124.6 14.1 124.6 124.6 119.0 102.8 86.7 70.5 114.6 15.6 114.6 114.6 110.1 94.3 78.4 62.6
5000
77 169.7 14.7 88.1 68.8 51.0 - - - 157.3 16.1 89.6 65.1 47.7 - - -
72 155.0 14.5 114.2 96.4 78.6 60.8 - - 143.1 15.9 109.2 91.8 74.4 57.0 - -
67 140.2 14.3 140.2 123.9 106.1 88.3 70.5 - 128.9 15.7 128.9 118.6 101.1 83.7 66.3 -
62 129.1 14.1 129.1 129.1 131.7 113.9 96.1 78.3 119.7 15.5 119.7 119.7 119.7 108.4 91.0 73.6
57 127.4 14.2 127.4 127.4 127.7 109.9 92.1 74.3 117.0 15.6 117.0 117.0 117.0 100.6 83.2 65.7
5625
72 155.6 14.6 123.2 103.8 84.3 64.9 - - 143.2 16.0 118.9 99.7 80.4 61.2 - -
67 140.8 14.4 140.8 132.6 113.9 94.4 74.9 - 128.9 15.8 128.9 127.5 109.3 90.0 70.8 -
62 129.6 14.1 129.6 129.6 130.9 111.4 92.0 72.5 119.8 15.6 119.8 119.8 119.8 103.6 84.3 65.1
57 127.9 14.2 127.9 127.9 128.1 108.6 89.1 69.7 117.0 15.6 117.0 117.0 117.0 98.3 79.0 59.8
6250
72 156.2 14.6 132.3 111.2 90.1 69.0 - - 143.3 16.0 128.6 107.5 86.4 65.3 - -
67 141.4 14.4 141.4 141.4 121.6 100.5 79.4 - 129.0 15.8 129.0 129.0 117.4 96.3 75.2 -
62 130.1 14.2 130.1 130.1 130.1 109.0 87.9 66.8 119.9 15.6 119.9 119.9 119.9 98.8 77.7 56.5
57 128.4 14.2 128.4 128.4 128.4 107.3 86.2 65.1 117.1 15.7 117.1 117.1 117.1 96.0 74.9 53.8
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
ZH150 (12.5 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
