528150-YTG-G-1210
64 Johnson Controls Unitary Products
115°F 125°F
2500
77 113.0 11.0 47.0 40.7 30.0 - - - 101.1 12.1 44.1 37.0 26.4 - - -
72 104.5 11.0 69.2 58.5 47.8 37.1 - - 93.6 12.1 65.1 54.5 43.9 33.3 - -
67 96.0 11.0 91.4 76.3 65.6 55.0 44.3 - 86.1 12.1 86.1 72.0 61.4 50.8 40.2 -
62 89.7 11.0 89.7 89.7 79.8 69.1 58.4 47.7 81.3 12.1 81.3 81.3 74.1 63.0 52.3 41.7
3000
77 119.6 11.1 58.6 46.1 33.6 - - - 108.1 12.1 57.2 42.5 30.0 - - -
72 110.6 11.1 78.6 66.1 53.5 41.0 - - 100.1 12.2 74.7 62.2 49.8 37.3 - -
67 101.6 11.1 98.5 86.0 73.5 61.0 48.5 - 92.1 12.2 92.1 82.0 69.5 57.1 44.6 -
62 94.9 11.0 94.9 94.9 89.3 76.8 64.3 51.8 87.0 12.2 87.0 87.0 83.3 70.9 58.4 46.0
57 94.9 11.0 94.9 94.9 85.5 73.0 60.5 47.9 86.7 12.0 86.7 86.7 77.8 65.3 52.9 40.4
3500
77 126.1 11.2 70.2 51.5 37.2 - - - 115.1 12.2 70.3 47.9 33.6 - - -
72 116.6 11.2 87.9 73.6 59.3 44.9 - - 106.6 12.3 84.2 69.9 55.6 41.3 - -
67 107.2 11.2 105.6 95.7 81.4 67.0 52.7 - 98.1 12.3 98.1 92.0 77.7 63.4 49.1 -
62 100.1 11.1 100.1 100.1 98.9 84.6 70.2 55.9 92.6 12.3 92.6 92.6 92.6 78.8 64.6 50.3
57 100.1 11.0 100.1 100.1 94.6 80.3 66.0 51.6 92.3 12.1 92.3 92.3 87.0 72.7 58.4 44.1
4000
77 132.7 11.3 81.8 56.9 40.8 - - - 122.2 12.3 83.4 53.3 37.1 - - -
72 122.7 11.3 97.3 81.1 65.0 48.8 - - 113.1 12.4 93.7 77.6 61.5 45.3 - -
67 112.7 11.3 112.7 105.4 89.2 73.1 56.9 - 104.1 12.4 104.1 102.0 85.8 69.7 53.6 -
62 105.3 11.2 105.3 105.3 108.4 92.3 76.1 60.0 98.2 12.4 98.2 98.2 98.2 86.8 70.7 54.5
57 105.3 11.1 105.3 105.3 103.7 87.6 71.5 55.3 98.0 12.2 98.0 98.0 96.2 80.0 63.9 47.8
4500
72 123.4 11.2 104.9 87.3 69.6 52.0 - - 113.1 12.3 100.8 83.3 65.8 48.3 - -
67 113.3 11.2 113.3 109.7 95.6 78.0 60.4 - 104.1 12.3 104.1 104.0 91.9 74.4 56.9 -
62 105.9 11.2 105.9 105.9 107.5 89.8 72.2 54.6 98.2 12.3 98.2 98.2 98.2 83.1 65.6 48.1
57 105.9 11.1 105.9 105.9 105.1 87.5 69.9 52.2 98.0 12.2 98.0 98.0 97.1 79.6 62.1 44.6
5000
72 124.0 11.2 112.5 93.4 74.3 55.2 - - 113.1 12.3 107.8 89.0 70.1 51.3 - -
67 113.9 11.2 113.9 113.9 102.0 82.9 63.8 - 104.1 12.3 104.1 104.1 97.9 79.1 60.3 -
62 106.5 11.2 106.5 106.5 106.5 87.4 68.3 49.2 98.2 12.3 98.2 98.2 98.2 79.4 60.6 41.7
57 106.4 11.1 106.4 106.4 106.4 87.3 68.3 49.2 98.0 12.1 98.0 98.0 98.0 79.1 60.3 41.5
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
ZJ120 (10 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
