528150-YTG-G-1210
56 Johnson Controls Unitary Products
115°F 125°F
1250
77 58.5 4.9 22.3 20.4 14.9 - - - 53.4 5.3 21.9 17.7 13.3 - - -
72 52.4 4.8 33.7 28.3 22.8 17.4 - - 47.6 5.2 31.8 26.4 21.0 15.6 - -
67 46.3 4.7 45.1 36.1 30.7 25.2 19.8 - 41.7 5.1 41.7 34.1 28.7 23.4 18.0 -
62 43.3 4.7 43.3 43.3 34.8 29.3 23.9 18.4 40.0 5.0 40.0 40.0 31.2 25.8 20.5 15.1
1500
77 60.5 4.9 29.6 23.1 16.7 - - - 55.1 5.3 29.6 21.3 14.9 - - -
72 54.2 4.9 38.3 31.9 25.5 19.0 - - 49.1 5.3 36.3 29.9 23.6 17.2 - -
67 47.9 4.8 47.1 40.7 34.3 27.8 21.4 - 43.0 5.2 43.0 38.6 32.2 25.8 19.5 -
62 44.8 4.7 44.8 44.8 38.9 32.4 26.0 19.6 41.2 5.1 41.2 41.2 35.0 28.6 22.3 15.9
57 43.1 4.7 43.1 43.1 38.5 32.1 25.7 19.2 39.7 5.1 39.7 39.7 35.4 29.0 22.6 16.3
1750
77 62.5 5.0 36.8 25.9 18.4 - - - 56.8 5.4 37.4 24.8 16.5 - - -
72 56.0 4.9 43.0 35.6 28.1 20.7 - - 50.6 5.3 40.8 33.5 26.1 18.7 - -
67 49.5 4.8 49.1 45.3 37.8 30.4 23.0 - 44.3 5.2 44.3 43.0 35.7 28.3 20.9 -
62 46.3 4.7 46.3 46.3 42.9 35.5 28.1 20.7 42.5 5.1 42.5 42.5 38.8 31.4 24.1 16.7
57 44.5 4.7 44.5 44.5 42.6 35.1 27.7 20.3 40.9 5.1 40.9 40.9 39.2 31.8 24.5 17.1
2000
77 64.5 5.0 44.1 28.6 20.2 - - - 58.5 5.5 45.1 28.4 18.1 - - -
72 57.8 5.0 47.6 39.2 30.8 22.4 - - 52.1 5.4 45.4 37.0 28.6 20.3 - -
67 51.1 4.9 51.1 49.8 41.4 33.0 24.6 - 45.6 5.3 45.6 45.6 39.2 30.8 22.4 -
62 47.8 4.8 47.8 47.8 47.0 38.6 30.2 21.8 43.8 5.2 43.8 43.8 42.6 34.2 25.9 17.5
57 45.9 4.8 45.9 45.9 46.6 38.2 29.8 21.4 42.2 5.2 42.2 42.2 42.2 34.7 26.3 17.9
2250
72 58.7 5.0 51.8 42.5 33.3 24.0 - - 52.7 5.4 49.5 40.2 31.0 21.8 - -
67 51.9 4.9 51.9 51.3 44.7 35.5 26.2 - 46.2 5.3 46.2 46.2 42.4 33.1 23.9 -
62 48.6 4.8 48.6 48.6 48.2 38.9 29.6 20.4 44.3 5.2 44.3 44.3 43.7 34.5 25.3 16.1
57 46.7 4.8 46.7 46.7 47.0 37.7 28.5 19.2 42.7 5.2 42.7 42.7 42.7 33.9 24.7 15.5
2500
72 59.6 5.0 55.9 45.8 35.7 25.6 - - 53.4 5.4 53.4 43.4 33.4 23.3 - -
67 52.7 4.9 52.7 52.7 48.0 37.9 27.7 - 46.8 5.3 46.8 46.8 45.6 35.5 25.4 -
62 49.3 4.8 49.3 49.3 49.3 39.2 29.1 19.0 44.9 5.2 44.9 44.9 44.9 34.8 24.7 14.6
57 47.4 4.8 47.4 47.4 47.4 37.3 27.1 17.0 43.3 5.2 43.3 43.3 43.3 33.2 23.1 13.0
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
ZJ061 (5.0 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
