528150-YTG-G-1210
84 Johnson Controls Unitary Products
ZR102 (8.5 Ton) Cooling
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
2125
77 121.9 6.4 54.3 43.2 32.9 - - - 118.7 7.4 52.3 42.1 32.0 - - -
72 118.1 6.4 71.1 60.8 50.5 40.2 - - 112.8 7.3 69.0 58.8 48.6 38.5 - -
67 114.3 6.3 87.8 78.4 68.1 57.8 47.5 - 106.9 7.2 85.6 75.4 65.3 55.1 45.0 -
62 105.8 6.2 105.8 98.7 83.7 73.4 63.1 52.8 98.9 7.0 98.9 95.3 80.2 70.1 59.9 49.8
2550
77 126.3 6.5 59.7 47.9 36.1 - - - 122.9 7.4 58.7 46.9 35.2 - - -
72 122.4 6.4 79.1 67.3 55.5 43.7 - - 116.8 7.3 77.0 65.3 53.5 41.8 - -
67 118.4 6.4 98.4 86.6 74.8 63.0 51.2 - 110.7 7.2 95.3 83.6 71.9 60.1 48.4 -
62 109.7 6.2 109.7 104.9 92.0 80.2 68.4 56.6 102.4 7.1 102.4 100.1 88.3 76.6 64.9 53.1
57 107.0 6.3 107.0 107.0 97.1 85.3 73.5 61.7 99.6 7.1 99.6 99.6 90.0 78.3 66.5 54.8
2975
77 130.7 6.5 65.1 52.7 39.4 - - - 127.2 7.4 65.0 51.7 38.4 - - -
72 126.6 6.4 87.0 73.7 60.5 47.2 - - 120.9 7.3 85.0 71.7 58.4 45.1 - -
67 122.6 6.4 108.9 94.8 81.5 68.2 54.9 - 114.6 7.2 105.1 91.7 78.4 65.1 51.8 -
62 113.5 6.3 113.5 111.1 100.2 86.9 73.6 60.3 106.0 7.1 106.0 104.8 96.4 83.1 69.8 56.5
57 110.8 6.3 110.8 110.8 105.8 92.5 79.2 65.9 103.0 7.2 103.0 103.0 98.2 84.9 71.6 58.3
3400
77 135.1 6.5 70.6 57.4 42.6 - - - 131.4 7.4 71.4 56.5 41.7 - - -
72 130.9 6.5 95.0 80.2 65.4 50.6 - - 124.9 7.3 93.1 78.2 63.3 48.4 - -
67 126.7 6.4 119.5 103.0 88.2 73.4 58.6 - 118.4 7.2 114.8 99.9 85.0 70.1 55.2 -
62 117.3 6.3 117.3 117.3 108.5 93.7 78.9 64.1 109.5 7.1 109.5 109.5 104.5 89.6 74.7 59.8
57 114.5 6.4 114.5 114.5 114.5 99.7 84.9 70.1 106.5 7.2 106.5 106.5 106.5 91.6 76.7 61.8
3825
72 130.9 6.5 99.4 84.1 68.8 53.5 - - 125.4 7.4 98.3 82.6 66.9 51.2 - -
67 126.8 6.4 123.1 108.1 92.8 77.5 62.2 - 118.8 7.3 117.0 105.4 89.7 74.0 58.4 -
62 117.4 6.3 117.4 117.4 112.9 97.6 82.3 67.0 109.9 7.1 109.9 109.9 107.4 91.7 76.0 60.3
57 114.5 6.4 114.5 114.5 114.5 99.2 83.9 68.6 106.9 7.2 106.9 106.9 106.9 91.2 75.5 59.8
4250
72 131.0 6.5 103.7 87.9 72.1 56.3 - - 125.9 7.4 103.4 86.9 70.4 53.9 - -
67 126.8 6.5 126.8 113.1 97.3 81.5 65.7 - 119.3 7.3 119.3 111.0 94.5 78.0 61.5 -
62 117.4 6.3 117.4 117.4 117.4 101.6 85.8 70.0 110.4 7.2 110.4 110.4 110.4 93.8 77.3 60.8
57 114.6 6.4 114.6 114.6 114.6 98.8 83.0 67.2 107.3 7.2 107.3 107.3 107.3 90.7 74.2 57.7
95°F 105°F
2125
77 115.5 8.3 50.3 41.1 31.1 - - - 108.8 9.3 44.7 38.2 28.2 - - -
72 107.5 8.1 66.9 56.8 46.8 36.8 - - 100.5 9.1 63.5 53.6 43.7 33.8 - -
67 99.5 8.0 83.4 72.5 62.5 52.5 42.4 - 92.1 9.0 82.4 69.0 59.1 49.2 39.3 -
62 91.9 7.9 91.9 91.9 76.8 66.8 56.7 46.7 85.2 8.9 85.2 85.2 70.3 60.4 50.5 40.6
2550
77 119.5 8.3 57.6 46.0 34.3 - - - 112.4 9.3 54.4 42.9 31.3 - - -
72 111.3 8.2 75.0 63.3 51.6 39.9 - - 103.8 9.2 71.5 60.0 48.4 36.8 - -
67 103.0 8.0 92.3 80.6 68.9 57.2 45.6 - 95.1 9.0 88.6 77.1 65.5 53.9 42.3 -
62 95.2 7.9 95.2 95.2 84.7 73.0 61.3 49.7 88.0 8.9 88.0 88.0 77.9 66.3 54.7 43.1
57 92.1 7.9 92.1 92.1 82.9 71.2 59.6 47.9 85.8 9.0 85.8 85.8 76.4 64.9 53.3 41.7
2975
77 123.6 8.3 64.9 50.8 37.5 - - - 115.9 9.4 64.2 47.5 34.3 - - -
72 115.1 8.2 83.1 69.7 56.4 43.1 - - 107.0 9.2 79.5 66.3 53.1 39.8 - -
67 106.5 8.0 101.2 88.7 75.3 62.0 48.7 - 98.1 9.0 94.9 85.1 71.8 58.6 45.4 -
62 98.5 7.9 98.5 98.5 92.6 79.3 65.9 52.6 90.8 8.9 90.8 90.8 85.4 72.2 58.9 45.7
57 95.2 8.0 95.2 95.2 90.7 77.3 64.0 50.7 88.5 9.0 88.5 88.5 83.8 70.6 57.4 44.1
3400
77 127.7 8.4 72.3 55.6 40.7 - - - 119.5 9.4 74.0 52.2 37.3 - - -
72 118.9 8.2 91.2 76.2 61.2 46.3 - - 110.3 9.2 87.6 72.7 57.8 42.9 - -
67 110.1 8.1 110.1 96.7 81.8 66.8 51.8 - 101.2 9.1 101.2 93.1 78.2 63.3 48.4 -
62 101.7 8.0 101.7 101.7 100.5 85.5 70.6 55.6 93.6 8.9 93.6 93.6 93.0 78.1 63.2 48.3
57 98.4 8.0 98.4 98.4 98.4 83.4 68.5 53.5 91.2 9.0 91.2 91.2 91.2 76.4 61.5 46.6
3825
72 119.8 8.3 97.1 81.0 64.9 48.8 - - 111.2 9.3 93.4 77.4 61.3 45.3 - -
67 110.9 8.1 110.9 102.8 86.7 70.6 54.5 - 102.0 9.1 102.0 97.2 83.0 67.0 51.0 -
62 102.5 8.0 102.5 102.5 101.9 85.8 69.7 53.6 94.3 9.0 94.3 94.3 94.0 78.0 61.9 45.9
57 99.2 8.0 99.2 99.2 99.2 83.1 67.0 50.9 92.0 9.1 92.0 92.0 92.0 75.9 59.9 43.9
4250
72 120.8 8.3 103.1 85.9 68.6 51.4 - - 112.1 9.3 99.2 82.1 64.9 47.7 - -
67 111.8 8.1 111.8 108.9 91.7 74.4 57.2 - 102.8 9.1 102.8 101.3 87.8 70.7 53.5 -
62 103.3 8.0 103.3 103.3 103.3 86.1 68.9 51.6 95.1 9.0 95.1 95.1 95.1 77.9 60.7 43.5
57 99.9 8.1 99.9 99.9 99.9 82.7 65.5 48.3 92.7 9.1 92.7 92.7 92.7 75.5 58.4 41.2
