528150-YTG-G-1210
48 Johnson Controls Unitary Products
115°F 125°F
2500
77 118.1 11.1 48.5 41.2 30.6 - - - 106.7 12.3 43.2 38.1 27.7 - - -
72 110.4 11.1 69.4 58.8 48.3 37.8 - - 100.8 12.2 65.9 55.6 45.2 34.8 - -
67 102.7 11.1 90.2 76.5 66.0 55.5 44.9 - 95.0 12.2 88.2 73.0 62.7 52.3 41.9 -
62 93.3 11.1 93.3 93.3 80.0 69.5 59.0 48.5 86.7 12.2 86.7 86.7 78.2 66.5 56.1 45.7
3000
77 120.6 11.2 57.9 45.7 33.6 - - - 109.0 12.3 54.4 42.4 30.4 - - -
72 112.8 11.1 77.2 65.1 52.9 40.8 - - 103.0 12.2 73.6 61.6 49.6 37.6 - -
67 104.9 11.1 96.6 84.5 72.3 60.2 48.0 - 97.0 12.2 92.7 80.8 68.8 56.8 44.8 -
62 95.3 11.1 95.3 95.3 87.7 75.6 63.4 51.3 88.5 12.2 88.5 88.5 84.3 72.3 60.3 48.3
57 97.8 11.0 97.8 97.8 87.5 75.4 63.2 51.1 90.9 12.1 90.9 90.9 81.8 69.8 57.8 45.8
3500
77 123.2 11.2 67.3 50.3 36.5 - - - 111.2 12.3 65.5 46.7 33.1 - - -
72 115.1 11.2 85.1 71.3 57.6 43.8 - - 105.1 12.3 81.2 67.6 54.0 40.4 - -
67 107.1 11.1 103.0 92.4 78.6 64.9 51.1 - 99.0 12.2 97.3 88.5 74.9 61.2 47.6 -
62 97.3 11.1 97.3 97.3 95.4 81.6 67.8 54.1 90.4 12.3 90.4 90.4 90.4 78.1 64.5 50.9
57 99.9 11.0 99.9 99.9 95.2 81.4 67.6 53.9 92.8 12.2 92.8 92.8 89.0 75.4 61.8 48.2
4000
77 125.7 11.2 76.7 54.8 39.5 - - - 113.5 12.3 76.6 51.0 35.8 - - -
72 117.5 11.2 93.0 77.6 62.2 46.8 - - 107.3 12.3 88.8 73.6 58.4 43.1 - -
67 109.3 11.1 109.3 100.4 85.0 69.6 54.2 - 101.0 12.3 101.0 96.2 80.9 65.7 50.5 -
62 99.3 11.1 99.3 99.3 103.1 87.7 72.3 56.9 92.2 12.3 92.2 92.2 92.2 84.0 68.8 53.5
57 101.9 11.1 101.9 101.9 102.8 87.4 72.0 56.7 94.7 12.2 94.7 94.7 94.7 81.1 65.8 50.6
4500
72 118.9 11.2 99.9 83.3 66.6 50.0 - - 107.9 12.3 95.4 79.0 62.7 46.3 - -
67 110.6 11.1 110.6 106.1 91.0 74.4 57.8 - 101.7 12.3 101.7 100.9 86.9 70.5 54.2 -
62 100.5 11.1 100.5 100.5 102.3 85.7 69.1 52.4 92.8 12.3 92.8 92.8 92.8 80.0 63.6 47.3
57 103.1 11.1 103.1 103.1 103.6 86.9 70.3 53.7 95.3 12.2 95.3 95.3 95.3 79.7 63.4 47.0
5000
72 120.2 11.2 106.8 89.0 71.1 53.2 - - 108.6 12.3 101.9 84.4 67.0 49.5 - -
67 111.9 11.1 111.9 111.9 97.1 79.2 61.4 - 102.3 12.3 102.3 102.3 92.9 75.4 57.9 -
62 101.6 11.1 101.6 101.6 101.6 83.7 65.9 48.0 93.4 12.3 93.4 93.4 93.4 76.0 58.5 41.0
57 104.3 11.1 104.3 104.3 104.3 86.4 68.6 50.7 95.9 12.2 95.9 95.9 95.9 78.4 60.9 43.4
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
ZH120 (10 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
