528150-YTG-G-1210
12 Johnson Controls Unitary Products
Guide Specifications
GENERAL
Units shall be manufactured by Unitary Products in an ISO
9001 certified facility. YORK® Predator
®
units are convertible
single packages with a common footprint cabinet and common
roof curb for all 3 through 12-1/2 ton models. All 6-1/2 through
12-1/2 ton units have two compressors with independent R-
410A refrigeration circuits to provide 2 stages of cooling. The
units were designed for light commercial applications and can
be easily installed on a roof curb, slab, or frame. All Predator
®
units are self-contained and assembled on rigid full perimeter
base rails allowing for 3-way forklift access and overhead
rigging. Every unit is completely charged with R-410A, wired,
piped, and tested at the factory to provide a quick and easy
field installation. All units are convertible between side and
down airflow. Independent economizer designs are used on
side and down discharge applications, as well as all tonnage
sizes. Predator
®
units are available in the following
configurations: cooling only, cooling with electric heat, cooling
with gas heat, reheat only, reheat with electric heat and reheat
with gas heat. Electric heaters are available as factory-installed
options or field-installed accessories.
DESCRIPTION
Units shall be factory assembled, single package, (Elec/Elec, Gas/
Elec), designed for outdoor installation. They shall have built in
field convertible duct connections for down discharge supply/return
or horizontal discharge supply/return and be available with factory
installed options or field installed accessories. The units shall be
Field Installed Acessories - Fresh Air
MODEL VOLTAGE DESCRIPTION WHERE USED
1EH0407
All
Barometric Relief Kit for Power Exhaust, Downflow
Application (Includes Hood) All Cabinets
1EH0408 All
Barometric Relief Kit for Power Exhaust, Horizontal
Application All Cabinets
1EH0409 All
Barometric Relief/Hood Kit - Required for field installed
slab economizer without ERV All Cabinets
1FA0413 All Manual Outside Air Damper 0-35%, Downflow All Cabinets
1FA0414 All Manual Outside Air Damper 0-100%, Downflow All Cabinets
1RD0411 All Barometric Relief Kit for Horizontal Applications All Cabinets
2EC04700924 All Dual Enthalpy Control All Cabinets
2EE04705724 All
Downflow Economizer, Slab type for ERV, (no
Barometric Relief or FA hood) All 50" Cabinets
2EE04705824 All
Downflow Economizer, Slab type for ERV, (no
Barometric Relief or FA hood) All 42" Cabinets
2EE04705924 All Downflow Economizer with Barometric Relief All Cabinets
2EE04706024 All Horizontal Economizer without Barometric Relief All Cabinets
2MD04703224 All Motorized Damper, Downflow without Barometric Relief All Cabinets
2MD04703724 All Motorized Damper, Horizontal All Cabinets
2PE04703225* 230 Power Exhaust 230V Downflow or Horizontal All Cabinets
2PE04703246* 460 Power Exhaust 460V Downflow or Horizontal All Cabinets
2PE04703258* 575 Power Exhaust 575V Downflow or Horizontal All Cabinets
* Must be installed in return Duct on Horizontal Applications and a 1EH0408 is required.
Field Installed Acessories - Controls
MODEL VOLTAGE DESCRIPTION WHERE USED
2AP0401 All Air Proving Switch All Units
2AQ04700324B All CO² Space Accessory All Units
2AQ04700424C All CO² Unit Accessory All Units
2DF0402 All Dirty Air Switch All Units
2DH04700024 All Humidistat All Units
2SD04700624 All Smoke Detector for Supply or Return
All Gen 4 or older units with 2" Filter only capable
Cabinets
2SD04700824 All Smoke Detector for Supply All Gen 5 units with 2" & 4" Filters
2SD04700924 All Smoke Detector for Return All Gen 5 units with 2" & 4" Filters
2SD04701024 All Smoke Detector for Supply and Return All Gen 5 units with 2" & 4" Filters
Field Installed Acessories - Electrical
MODEL VOLTAGE DESCRIPTION WHERE USED
2BC04700106 230 Gas heat kit, -60ºF All Units
2BC04700151 460 Gas heat kit, -60ºF All Units
2BC04700154 575 Gas heat kit, -60ºF All Units
2LA04704632 All Low Ambient Kit All 3 - 10T units (excludes 12.5T "V" cabinets)
2LA04704634 All Low Ambient Kit All 3 - 5T Reheat Units (Only)
Accessories (Continued)
