528150-YTG-G-1210
Johnson Controls Unitary Products 53
ZJ049 (4.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1000
77 63.4 2.7 27.1 22.3 17.7 - - - 59.7 3.1 25.2 20.6 16.0 - - -
72 58.0 2.7 33.7 29.0 24.4 19.7 - - 54.2 3.1 31.8 27.3 22.7 18.1 - -
67 52.7 2.7 40.2 35.7 31.0 26.4 21.7 - 48.6 3.1 38.5 33.9 29.3 24.7 20.2 -
62 45.3 2.7 45.3 45.3 37.4 32.7 28.0 23.4 42.5 3.1 42.5 42.5 35.9 31.3 26.7 22.1
1200
77 66.8 2.6 30.6 25.2 19.7 - - - 62.5 3.1 28.6 23.2 17.9 - - -
72 61.1 2.7 38.1 32.6 27.2 21.7 - - 56.7 3.1 36.0 30.6 25.3 19.9 - -
67 55.4 2.7 45.5 40.1 34.6 29.2 23.7 - 50.9 3.1 43.4 38.0 32.6 27.3 21.9 -
62 47.7 2.7 47.7 47.7 41.7 36.3 30.8 25.4 44.5 3.1 44.5 44.5 39.9 34.6 29.2 23.9
57 45.7 2.7 45.7 45.7 42.8 37.4 31.9 26.5 43.0 3.1 43.0 43.0 39.9 34.6 29.2 23.8
1400
77 70.1 2.6 34.1 28.0 21.8 - - - 65.3 3.1 31.9 25.8 19.7 - - -
72 64.2 2.7 42.5 36.3 30.0 23.8 - - 59.2 3.1 40.1 34.0 27.8 21.7 - -
67 58.2 2.7 50.9 44.5 38.3 32.0 25.8 - 53.2 3.1 48.2 42.1 36.0 29.8 23.7 -
62 50.1 2.7 50.1 50.1 46.1 39.8 33.6 27.3 46.5 3.1 46.5 46.5 44.0 37.9 31.7 25.6
57 48.0 2.7 48.0 48.0 47.3 41.0 34.8 28.6 44.9 3.1 44.9 44.9 44.0 37.8 31.7 25.6
1600
77 73.5 2.6 37.6 30.9 23.8 - - - 68.1 3.1 35.3 28.4 21.5 - - -
72 67.2 2.7 46.9 39.9 32.9 25.8 - - 61.8 3.1 44.2 37.3 30.4 23.5 - -
67 61.0 2.7 56.2 48.9 41.9 34.8 27.8 - 55.5 3.1 53.1 46.2 39.3 32.4 25.5 -
62 52.5 2.7 52.5 52.5 50.4 43.4 36.3 29.3 48.5 3.1 48.5 48.5 48.0 41.1 34.2 27.3
57 50.3 2.7 50.3 50.3 51.7 44.7 37.7 30.6 46.9 3.1 46.9 46.9 48.0 41.1 34.2 27.3
1800
72 68.4 2.7 50.4 42.5 34.7 26.8 - - 62.8 3.1 47.5 39.9 32.2 24.5 - -
67 62.0 2.7 59.6 52.0 44.2 36.3 28.5 - 56.4 3.1 55.3 49.3 41.6 33.9 26.2 -
62 53.4 2.7 53.4 53.4 52.4 44.5 36.7 28.8 49.3 3.1 49.3 49.3 49.1 41.4 33.8 26.1
57 51.2 2.7 51.2 51.2 51.9 44.0 36.2 28.4 47.7 3.0 47.7 47.7 48.3 40.6 32.9 25.2
2000
72 69.6 2.6 53.8 45.2 36.5 27.8 - - 63.9 3.0 50.9 42.4 34.0 25.5 - -
67 63.1 2.7 63.1 55.2 46.5 37.8 29.2 - 57.4 3.0 57.4 52.4 43.9 35.5 27.0 -
62 54.4 2.7 54.4 54.4 54.4 45.7 37.0 28.4 50.2 3.1 50.2 50.2 50.2 41.7 33.3 24.8
57 52.1 2.7 52.1 52.1 52.1 43.4 34.7 26.1 48.5 3.0 48.5 48.5 48.5 40.0 31.6 23.1
95°F 105°F
1000
77 55.9 3.5 23.3 18.9 14.4 - - - 50.7 3.9 20.2 17.0 12.6 - - -
72 50.3 3.4 30.0 25.5 21.0 16.5 - - 45.2 3.8 27.9 23.5 19.1 14.6 - -
67 44.6 3.4 36.7 32.1 27.6 23.1 18.6 - 39.7 3.7 35.7 30.0 25.5 21.1 16.7 -
62 39.7 3.4 39.7 39.7 34.4 29.9 25.4 20.9 34.7 3.8 34.7 34.7 30.7 26.3 21.9 17.4
1200
77 58.1 3.5 26.5 21.3 16.0 - - - 52.6 3.9 24.6 19.2 14.0 - - -
72 52.3 3.4 33.8 28.6 23.3 18.1 - - 46.9 3.8 31.5 26.4 21.2 16.1 - -
67 46.4 3.4 41.2 35.9 30.6 25.4 20.1 - 41.2 3.7 38.5 33.6 28.4 23.3 18.1 -
62 41.3 3.4 41.3 41.3 38.1 32.9 27.6 22.4 36.0 3.8 36.0 36.0 34.2 29.1 23.9 18.8
57 40.3 3.4 40.3 40.3 37.0 31.7 26.5 21.2 36.7 3.7 36.7 36.7 33.4 28.3 23.1 18.0
1400
77 60.4 3.5 29.8 23.6 17.6 - - - 54.6 3.9 29.0 21.4 15.5 - - -
72 54.3 3.4 37.7 31.6 25.6 19.6 - - 48.6 3.8 35.2 29.3 23.4 17.5 - -
67 48.2 3.4 45.6 39.7 33.7 27.6 21.6 - 42.7 3.7 41.3 37.2 31.3 25.5 19.6 -
62 42.9 3.4 42.9 42.9 41.9 35.9 29.9 23.9 37.4 3.8 37.4 37.4 37.7 31.9 26.0 20.1
57 41.8 3.4 41.8 41.8 40.7 34.6 28.6 22.6 38.0 3.7 38.0 38.0 36.9 31.0 25.1 19.2
1600
77 62.6 3.5 33.0 25.9 19.2 - - - 56.5 3.9 33.4 23.5 16.9 - - -
72 56.3 3.4 41.5 34.7 27.9 21.1 - - 50.3 3.8 38.8 32.2 25.6 19.0 - -
67 50.0 3.4 50.0 43.5 36.7 29.9 23.1 - 44.2 3.7 44.2 40.9 34.3 27.7 21.1 -
62 44.4 3.4 44.4 44.4 45.7 38.9 32.1 25.3 38.7 3.8 38.7 38.7 41.2 34.6 28.0 21.4
57 43.4 3.4 43.4 43.4 44.3 37.5 30.7 24.0 39.4 3.7 39.4 39.4 40.3 33.7 27.1 20.5
1800
72 57.3 3.5 44.7 37.2 29.7 22.2 - - 51.2 3.8 41.9 34.6 27.3 19.9 - -
67 50.9 3.4 50.9 46.5 39.0 31.5 24.0 - 45.0 3.8 45.0 42.8 36.5 29.2 21.8 -
62 45.2 3.5 45.2 45.2 45.8 38.3 30.8 23.3 39.4 3.8 39.4 39.4 40.7 33.3 26.0 18.6
57 44.2 3.4 44.2 44.2 44.6 37.1 29.6 22.1 40.1 3.7 40.1 40.1 40.5 33.2 25.9 18.5
2000
72 58.3 3.5 47.9 39.7 31.5 23.2 - - 52.1 3.8 45.1 37.0 28.9 20.9 - -
67 51.7 3.4 51.7 49.6 41.3 33.1 24.9 - 45.7 3.8 45.7 44.7 38.8 30.7 22.6 -
62 46.0 3.5 46.0 46.0 46.0 37.8 29.5 21.3 40.1 3.8 40.1 40.1 40.1 32.0 23.9 15.8
57 44.9 3.4 44.9 44.9 44.9 36.7 28.4 20.2 40.8 3.7 40.8 40.8 40.8 32.7 24.6 16.6
