528150-YTG-G-1210
Johnson Controls Unitary Products 73
ZR061 (5.0 Ton) Cooling
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1250
77 81.7 5.9 33.6 27.7 21.9 - - - 76.2 4.8 32.2 26.5 20.8 - - -
72 72.8 5.0 41.9 36.1 30.2 24.3 - - 67.8 4.3 40.1 34.3 28.6 22.9 - -
67 64.0 4.0 50.2 44.4 38.5 32.6 26.7 - 59.4 3.8 47.9 42.1 36.4 30.7 25.0 -
62 57.0 3.6 57.0 57.0 45.7 39.9 33.9 28.1 52.5 3.8 52.5 52.5 43.6 37.8 32.1 26.4
1500
77 85.0 5.4 37.9 31.1 24.3 - - - 79.0 4.6 36.2 29.6 23.0 - - -
72 75.8 4.5 47.1 40.4 33.6 26.8 - - 70.3 4.1 44.8 38.2 31.6 25.0 - -
67 66.6 3.6 56.4 49.6 42.9 36.1 29.3 - 61.6 3.7 53.4 46.8 40.2 33.6 27.0 -
62 59.3 3.2 59.3 59.3 50.9 44.1 37.4 30.6 54.5 3.6 54.5 54.5 48.1 41.4 34.8 28.2
57 58.1 4.1 58.1 58.1 52.1 45.3 38.6 31.8 53.9 4.1 53.9 53.9 48.7 42.1 35.4 28.8
1750
77 88.3 4.9 42.1 34.4 26.8 - - - 81.9 4.3 40.1 32.6 25.1 - - -
72 78.7 4.1 52.3 44.6 37.0 29.4 - - 72.9 3.9 49.5 42.0 34.5 27.0 - -
67 69.2 3.2 62.5 54.8 47.2 39.5 31.9 - 63.9 3.5 59.0 51.5 43.9 36.4 28.9 -
62 61.6 2.8 61.6 61.6 56.0 48.4 40.7 33.1 56.4 3.4 56.4 56.4 52.5 45.0 37.5 30.0
57 60.4 3.7 60.4 60.4 57.3 49.7 42.1 34.4 55.8 3.9 55.8 55.8 53.2 45.7 38.2 30.7
2000
77 91.6 4.4 46.3 37.8 29.3 - - - 84.7 4.1 44.0 35.6 27.2 - - -
72 81.7 3.6 57.5 48.9 40.4 31.9 - - 75.4 3.7 54.3 45.9 37.5 29.1 - -
67 71.8 2.8 68.6 60.1 51.5 43.0 34.5 - 66.1 3.3 64.5 56.1 47.7 39.3 30.9 -
62 63.9 2.5 63.9 63.9 61.2 52.7 44.1 35.6 58.4 3.2 58.4 58.4 57.0 48.6 40.2 31.8
57 62.6 3.2 62.6 62.6 62.6 54.1 45.6 37.0 57.8 3.6 57.8 57.8 57.8 49.4 41.0 32.6
2250
72 82.5 3.9 60.8 51.6 42.4 33.2 - - 75.9 3.9 57.9 48.8 39.7 30.6 - -
67 72.5 3.0 70.9 63.3 54.1 44.9 35.8 - 66.5 3.5 65.7 59.6 50.5 41.4 32.3 -
62 64.5 2.6 64.5 64.5 63.2 54.0 44.8 35.6 58.8 3.5 58.8 58.8 58.1 49.0 39.9 30.8
57 63.3 3.5 63.3 63.3 63.3 54.1 44.9 35.7 58.2 3.9 58.2 58.2 58.2 49.1 39.9 30.8
2500
72 83.4 4.2 64.2 54.3 44.5 34.6 - - 76.4 4.1 61.6 51.7 41.9 32.1 - -
67 73.2 3.3 73.2 66.6 56.7 46.9 37.1 - 66.9 3.7 66.9 63.2 53.4 43.5 33.7 -
62 65.2 2.8 65.2 65.2 65.2 55.3 45.5 35.6 59.2 3.7 59.2 59.2 59.2 49.3 39.5 29.7
57 63.9 3.7 63.9 63.9 63.9 54.0 44.2 34.4 58.5 4.1 58.5 58.5 58.5 48.7 38.9 29.1
95°F 105°F
1250
77 70.7 3.7 30.8 25.3 19.7 - - - 65.8 4.9 25.3 21.7 16.5 - - -
72 62.8 3.7 38.2 32.6 27.0 21.5 - - 57.8 4.6 35.2 29.7 24.3 18.9 - -
67 54.8 3.7 45.5 39.9 34.3 28.8 23.2 - 49.8 4.3 45.1 37.8 32.1 26.6 21.2 -
62 48.1 4.0 48.1 48.1 41.4 35.8 30.3 24.7 43.0 4.6 43.0 43.0 35.7 30.3 24.8 19.4
1500
77 73.1 3.8 34.5 28.0 21.6 - - - 67.2 4.8 31.0 24.5 18.1 - - -
72 64.9 3.7 42.5 36.0 29.5 23.1 - - 59.0 4.5 39.4 33.0 26.6 20.2 - -
67 56.7 3.7 50.5 44.0 37.5 31.1 24.6 - 50.8 4.3 47.7 41.5 35.1 28.7 22.3 -
62 49.7 4.0 49.7 49.7 45.2 38.8 32.3 25.8 43.9 4.6 43.9 43.9 39.1 32.7 26.3 19.9
57 49.7 4.0 49.7 49.7 45.3 38.8 32.3 25.9 44.9 4.6 44.9 44.9 39.9 33.5 27.1 20.8
1750
77 75.5 3.8 38.2 30.8 23.4 - - - 68.6 4.7 36.8 27.3 19.7 - - -
72 67.0 3.7 46.8 39.4 32.1 24.7 - - 60.3 4.5 43.6 36.2 28.9 21.6 - -
67 58.5 3.7 55.4 48.1 40.7 33.3 26.0 - 51.9 4.2 50.4 45.2 38.1 30.8 23.5 -
62 51.3 4.0 51.3 51.3 49.1 41.7 34.3 27.0 44.9 4.5 44.9 44.9 42.5 35.1 27.8 20.4
57 51.3 4.0 51.3 51.3 49.1 41.7 34.4 27.0 45.9 4.5 45.9 45.9 43.4 36.0 28.7 21.4
2000
77 77.9 3.8 41.8 33.5 25.2 - - - 70.0 4.7 42.5 30.0 21.2 - - -
72 69.1 3.8 51.1 42.8 34.6 26.3 - - 61.5 4.4 47.8 39.5 31.2 22.9 - -
67 60.4 3.7 60.4 52.2 43.9 35.6 27.3 - 53.0 4.1 53.0 48.9 41.2 32.9 24.6 -
62 52.9 4.0 52.9 52.9 52.9 44.6 36.4 28.1 45.8 4.4 45.8 45.8 45.8 37.5 29.2 21.0
57 52.9 4.1 52.9 52.9 52.9 44.7 36.4 28.1 46.8 4.4 46.8 46.8 46.8 38.5 30.3 22.0
2250
72 69.3 3.9 55.0 46.0 37.0 27.9 - - 61.6 4.6 51.5 42.5 33.4 24.3 - -
67 60.5 3.9 60.5 56.0 46.9 37.9 28.9 - 53.1 4.3 53.1 50.8 44.1 35.0 26.0 -
62 53.0 4.3 53.0 53.0 53.0 44.0 35.0 25.9 45.9 4.6 45.9 45.9 45.9 36.8 27.7 18.7
57 53.1 4.3 53.1 53.1 53.1 44.0 35.0 26.0 46.9 4.7 46.9 46.9 46.9 37.8 28.7 19.7
2500
72 69.4 4.1 58.9 49.1 39.4 29.6 - - 61.6 4.8 55.3 45.5 35.6 25.8 - -
67 60.7 4.1 60.7 59.8 50.0 40.2 30.4 - 53.1 4.5 53.1 52.7 47.0 37.2 27.3 -
62 53.2 4.5 53.2 53.2 53.2 43.4 33.6 23.8 45.9 4.8 45.9 45.9 45.9 36.1 26.2 16.4
57 53.2 4.5 53.2 53.2 53.2 43.4 33.6 23.8 46.9 4.9 46.9 46.9 46.9 37.1 27.2 17.4
