Detaching the embroidery unit
NOTE:
•Besuretoremovetheembroideryunitwhen
carrying or storing the machine.
•Iftheneedleisindownposition,makesureto
raise the needle by pressing the needle up/down
key.
z Remove the hoop from the carriage and return the
carriage to the home position (refer to page 122).
q Carriage arm release lever
w Carriage arm
WARNING:
Be careful not to get your finger caught between the
embroidery unit and machine bed with the extension
table removed when the carriage returns to home
position.
x Push down the carriage arm release lever to retract
the carriage arm.
t
e
r
c Turn the power switch off.
Push the embroidery unit release button.
Slide the embroidery unit to the left and remove it.
e Power switch
r Embroidery unit release button
v Attach the cover to the machine.
t Cover
z
x
c
v
q
w
