Saving and opening a file
Saving a file
The programmed pattern can be saved as a file in the
Built-in Memory or ATA PC card. There are 4 folders in
the built-in memory and 12 folders in the ATA PC card
for saving the files.
NOTES:
• Up to 100 files can be saved in each folder,
but total number of the files is limited by the
available memory size.
• The memory size of free space is displayed
on the screen.
1 When you press the key, the folder list
will be displayed on the screen.
2 Press the icon of the desired folder to select it
and the Save File box will open. The file name
will automatically assigned starting from
M_001.... in order.
3Press the key and the file will be saved in
the selected folder.
4To return to the previous screen, press the
return key.
Changing the folder name
5To change the folder name, press the
key and “Name” will turn red ( ).
Press the icon of the desired folder and the
keyboard window will open.
6 Enter the folder name and press the key.
Assigning a file name
You can assign the particular name to the file.
7 Press the key to open the keyboard
window.
8 Enter the file name and press the key.
The file will be saved with the new name.
NOTES:
• Only 8 characters can be entered.
• Press the key (back space) to delete the
last character.
• Press the key and the screen will return
to the folder list.
• When the memory is full, the warning message will
appear. Press the key and go to the open file
window then delete the file that you do not need.
• When you save a file under the same name, the
confirmation message will appear. Press the
key to overwrite the existing file. Press the key
if you do not wish to overwrite it
CAUTION:
Do not turn the power off or eject the card while the
hourglass or warning sign has been
displayed on the screen.
Otherwise the saved data will lost or the memory will
be damaged.
