Winding the Bobbin
Removing the bobbin
Slide the Hook Cover Plate Release Button
to the right, and remove the Hook Cover
Plate. Lift out the Bobbin from the Bobbin
Holder.
1 Hook Cover Plate Release Button
2 Hook Cover Plate
3 Bobbin
Setting the spool of thread
Lift up the Spool Pin. Place the spool of
thread on the Spool Pin with the thread
coming off the spool as shown. Attach the
Large Spool Holder, and press it firmly
against the spool of thread.
NOTE:
• Use the Small Spool Holder to hold
narrow or small spools of thread.
4 Spool Pin
5 Large Spool Holder
6 Small Spool Holder
Additional spool pin
Use the Additional Spool Pin when you need
to wind the bobbin without unthreading the
machine while working on a sewing project.
The Additional Spool Pin is also used for
twin needle sewing.
Insert the Additional Spool Pin into the Hole
beside the horizontal spool pin.
Place the Felt on the spool pin and place a
spool of thread on it as shown.
7 Additional Spool Pin
8Hole
9Felt
