Operating the Thermostat
43
V
iewStat Color Communicating Thermostat User Guide
10. Use the navigation buttons to highlight Advanced Setup, and press Mode/Select to access the
Advanced Setup screen.
11. Use the navigation buttons to highlight More, and press Mode/Select to access the second
Advanced Setup screen.
12. Use the navigation buttons to highlight Thermostat Setup, and press Mode/Select to access the
Thermostat Setup screen (see FIG. 34).
13. Use the navigation buttons to highlight Deadband, and press Mode/Select.
14. Press Mode/Select to indicate the deadband temperature difference.
Setting the Temperature Offset
The temperature offset enables you to customize the temperature shown on the display. You can set the
temperature offset in 1° increments.
Perform these steps to set the temperature offset:
1. From the Main screen, press Mode/Select to access the Current Weather screen.
2. Press Mode/Select to access the 5-Day Forecast screen.
3. Press Mode/Select to access the Thermostat Mode screen.
4. Use the navigation buttons to select Settings, and press Mode/Select to access the Settings screen.
5. Use the navigation buttons to select Advanced Setup.
6. Press Mode/Select to access the Security Code screen.
7. Enter the security code, and select Enter to access the User Preferences screen. See the Entering the
Security Code section on page 28 for more information.
8. Use the navigation buttons to highlight More, and press Mode/Select to access the second User
Preferences screen.
9. On the second User Preferences screen, use the navigation buttons to highlight More, and press
Mode/Select to access the third User Preferences screen.
10. Use the navigation buttons to highlight Advanced Setup, and press Mode/Select to access the
Advanced Setup screen.
11. Use the navigation buttons to highlight More, and press Mode/Select to access the second
Advanced Setup screen.
12. Use the navigation buttons to highlight Thermostat Setup, and press Mode/Select to access the
Thermostat Setup screen (see FIG. 34).
13. Use the navigation buttons to highlight Temperature Offset, and press Mode/Select.
14. Press Mode/Select to indicate the temperature offset.
Setting the Balance Point
Balance Point configuration enables you to adjust a balance point to limit auxiliary heat pump operation
according to the current outdoor temperature. The compressor terminals will not be energized when the
outdoor temperature is below the balance point. This does not affect Emergency Heat operation. This
option is only valid if the thermostat has been configured to operate as a heat pump.
Perform these steps to set the balance point:
1. From the Main screen, press Mode/Select to access the Current Weather screen.
2. Press Mode/Select to access the 5-Day Forecast screen.
3. Press Mode/Select to access the Thermostat Mode screen.
4. Use the navigation buttons to select Settings, and press Mode/Select to access the Settings screen.
