Operating the Thermostat
34
ViewStat Color Communicating Thermostat User Guide
9. Use the navigation buttons to highlight Button Lockout.
10. Press Mode/Select to access the Button Lockout screen (see FIG. 29).
11. With Button Lockout highlighted, press Mode/Select to toggle the button lockout setting between
Lock and Unlock.
Locking the Temperature Settings
You can lock the temperature settings on the thermostat so no one can change them. When you lock the
temperature settings, you must set an amount of time for the settings to be locked. You can set the time
limit to any amount of time between 0 and 60 minutes. After the time limit expires, the temperature
settings automatically unlock and can be changed again. Perform the following steps to lock the
temperature settings:
1. From the Main screen, press Mode/Select to access the Current Weather screen.
2. Press Mode/Select to access the 5-Day Forecast screen.
3. Press Mode/Select to access the Thermostat Mode screen.
4. Use the navigation buttons to select Settings, and press Mode/Select to access the Settings screen.
5. Use the navigation buttons to select Advanced Setup.
6. Press Mode/Select to access the Security Code screen.
7. Enter the security code, and select Enter to access the User Preferences screen. See the Entering the
Security Code section on page 28 for more information.
8. Use the navigation buttons to highlight More, and press Mode/Select to access the second User
Preferences screen.
9. Use the navigation buttons to highlight Button Lockout.
10. Press Mode/Select to access the Button Lockout screen (see FIG. 29).
11. Use the navigation buttons to select Temperature Lock, and press Mode/Select to toggle the
temperature lockout setting between Yes and No.
12. Use the navigation buttons to select Temperature Lock Time Limit, and press Mode/Select
activate it.
13. Press Mode/Select multiple times until you reach the time limit value you want.
14. Use the navigation buttons to select Temperature Lock Range Limit, and press Mode/Select
activate it.
15. Press Mode/Select multiple times until you reach the range limit value you want.
FIG. 29 Button Lockout screen (1 of 2)
