Setup and Configuration
13
ViewStat Color Communicating Thermostat User Guide
User Preferences Screen
The User Preferences screens (FIG. 11) enable you to establish personal preference settings for the
thermostat including temperature scale, date and time format, and brightness level. You can use the
navigation buttons to move through the highlighted options. The Mode/Select button selects the
highlighted item. You can then use the navigation buttons to change the setting of the highlighted option.
Pressing Mode/Select again highlights the next available option. The following table lists the options on
the User Preferences screen:
FIG. 11 User Preferences screens
User Preferences Screen Options
Temperature Scale Toggles between Celsius (C) and Fahrenheit (F).
Date Format Toggles between a date format of MMDDYY, DDMMYY, and YYDDMM.
Time Format Toggles between a 12- or 24-hour time format.
Backlight Timeout Establishes the amount of inactive time before the backlight on the unit
automatically turns off. You can set a value between 10 seconds and 5 minutes
in 10 second increments. The default value is 30 seconds.
Backlight Active Brightness Establishes the level of brightness for the backlight when the unit is active. You
can choose Low, Medium, or High.
Backlight Inactive Brightness Establishes the level of brightness for the backlight when the unit is inactive.
You can choose Dim or Off.
Filter Change Reminder Enables the reminder to periodically change the air filter. When you enable this
feature, the thermostat monitors the operation time of the HVAC system and
fan. When the operation time reaches the number of days you set on the
Settings screen, the filter change reminder icon displays alerting you to change
the filter.
Weather Alert Icon Enables a weather alert when the thermostat receives a weather alert channel
activation from the NI Master.
Current Weather Page Enables you to turn off the current weather screen on the thermostat. If you are
not using the i!-Weather application to report the weather forecast to the
thermostat, you might want to disable the current weather screen so it does not
appear when you navigate through the thermostat’s screens. If you disable the
forecast screens, only the indoor temperature displays on the Main screen.
Five Day Forecast Page Enables you to turn off the 5-Day Forecast screen on the thermostat. If you are
not using the i!-Weather application to report the weather forecast to the
thermostat, you might want to disable the 5-Day Forecast screen so it does not
appear when you navigate through the thermostat’s screens. If you disable the
forecast screens, only the indoor temperature displays on the Main screen.
Screensaver Enables you to turn on a screen saver for the thermostat. The screen saver
activates after 30 seconds without any user input, and displays the current
room temperature moving around the screen on a black background.
