26
JOHNSON CONTROLS
FORM 100.50-NOM6 (1207)
Installation
GENERAL ARRANGEMENT DRAWINGS (CONTINUED)
FIG. 2-4 – GENERAL ARRANGEMENT DRAWING (CONT.)
BOTTOM SUPPLY / SIDE RETURN
SECTION DESCRIPTIONS:
EE = Economizer
FE = Fan Exhaust
_F = Filter Segments
CC = Cooling Coils
FS = Supply Fan
DP = Discharge Plenum
CO = Condenser Section
LD08370
6.28
38.37
49.94 4.79
GAS
BURNERS
GAS LINE CONNECTION
2-1/2" GAS OUTLET
1-1/2" MPT CONN.
195.38
221.00
GAS HEAT FLUE
GAS HEAT EXHAUST FLUE
FIELD INSTALLED
102.62
TOP VIEW
REAR VIEW
SIDE VIEW
(LEFT SIDE)
FRONT VIEW
1.50
78.00 CLEAR
FOR COIL PULL
30.00
DOOR
SWING
CLEAR-
ANCE
BOTH
SIDES
95.25
92.00
82.00
84.00
CLEAR
91.00
CLEAR
FOR COIL
PULL
120.00 CLEAR
339.00
AIRFLOW
106.00
1-1/4" FPT DRAIN
LEFT SIDE ONLY
170.31
ELECTRICAL SERVICE
60.00 CLEAR
FOR AIR INTAKE
BOTH SIDES
136.82
OA OA
69.83
75.58
5.74
230.62
191.19
NOTES:
1. 10’ clearance minimal over the top of the condensing unit.
2. Only one adjacent wall can exceed unit height.
3. 12’ clearance required to adjacent units.
4. 8’ service access recommended on one side.
5. Economizer and exhaust hoods, where applicable are folded inside unit for shipment.
