133
JOHNSON CONTROLS
FORM 100.50-NOM6 (1207)
6
Continued on next page
TABLE - 6-2 - SIMPLICITY ELITE DATA MAP (CONT.)
ADDRESS
(HEX)
ADDRESS
(DEC)
BIT
INITIAL/
DEFAULT
VALUE
(HEX)
MIN
VALUE
MAX
VALUE
DESCRIPTION
0
BITS 1 AND 0 = 0,0 RESPECTIVELY THERE ARE 2 STAGES OF
COMPRESSION; 0,1 = 3 STAGES; 1,0 = 4 STAGES; 1,1 = 4
STAGES
1
2 1 = SAT LIMIT FOR COOLING ENABLED
3 1 = SAT LIMIT FOR HEATING ENABLED
4 1 = HYDRONIC HEATING ENABLED
5 1 = HYDRONIC HEAT ACTUATOR VALVE REVERSE ACTING
6 1 = REMOTE CONTROL INPUT ENABLED FOR THIRD PARTY BAS
7 1 = HOT GAS REHEAT ENABLED
1A L 26 L NA 4 - - OPTION BYTE #3
0 1 = VAV OCCUPIED HEATING ENABLED
1NA
2 1 = ECONOMIZER PRESENT
3 1 = OUTSIDE AIR HUMIDITY SENSOR PRESENT
4 1 = RETURN AIR HUMIDITY SENSOR PRESENT
5 1 = PRE-OCCUPANCY PURGE ENABLED
6 1 = DEMAND VENTILATION ENABLED
7 1 = BUILDING PRESSURE SENSOR INSTALLED
1B H 27 H NA 193 - - OPTION BYTE #4
0 1 = POWER EXHAUST PRESENT
1 1 = MODULATING POWER EXHAUST PRESENT
2 1 = EXHAUST VFD PRESENT
3 1 = LOW AMBIENT KIT INSTALLED
4 1 = DIRTY FILTER SWITCH PRESENT
5 1 = INTELLI-START OPERATION ENABLED
6 1 = INDOOR FAN OPERATES WITH SPACE SENSOR PRESENT [CV]
7 1 = DAYLIGHT SAVINGS TIME ENABLED
1B L 27 L NA 8 - - OPTION BYTE #5
0 1 = RUN TEST ENABLED
1 1 = METER OF UNOCCUPIED OVERRIDE ENABLED
2 1 = METRIC DISPLAY ENABLED
3
1 = USE THERMOSTAT OR COMMUNICATIONS FLAG FOR
OCCUPIED SIGNAL
4 1 = LEAD/LAG: EQUALIZE COMPRESSOR RUN TIME ENABLED
5 1 = HOT GAS BYPASS PRESENT ON COMPRESSOR #1
6 1 = THIRD PARTY BAS ECONOMIZER ENABLED
7 1 = MORNING WARM-UP ENABLED
1C H 28 H NA 0 0 255 ALARM 1 - MOST RECENT ALARM.
1C L 28 L NA 0 0 255 ALARM 2
1D H 29 H NA 0 0 255 ALARM 3
1D L 29 L NA 0 0 255 ALARM 4
1E H 30 H NA 0 0 255 ALARM 5 – OLDEST STORED ALARM.
