131
JOHNSON CONTROLS
FORM 100.50-NOM6 (1207)
6
ADDRESS
(HEX)
ADDRESS
(DEC)
BIT
INITIAL/
DEFAULT
VALUE
(HEX)
MIN
VALUE
MAX
VALUE
DESCRIPTION
5 1 = W2 ON (HEATING 2ND STAGE)
6 1 = W3 ON (HEATING 3RD STAGE)
7 1 = G ON (INDOOR FAN)
15 L 21 L NA - - - INPUT STATUS BYTE #2
0 1 = HPS1 CLOSED (NOT TRIPPED)
1 1 = HPS2 CLOSED
2 1 = HPS3 CLOSED
3 1 = HPS4 CLOSED
4 1 = LPS1 CLOSED (NOT TRIPPED)
5 1 = LPS2 CLOSED
6 1 = LPS3 CLOSED
7 1 = LPS4 CLOSED
16 H 22 H NA - - - INPUT STATUS BYTE #3
0 1 = C1 OVERLOAD CLOSED (NOT TRIPPED)
1 1 = C2 OVERLOAD CLOSED
2 1 = C3 OVERLOAD CLOSED
3 1 = C4 OVERLOAD CLOSED
4 1 = PURGE SWITCH CLOSED (ACTIVE)
5 1 = OCC INPUT ON
6NA
7 1 = DIRTY FILTER CLOSED (DIRTY CONDITION)
16 L 22 L NA - - - INPUT STATUS BYTE #4
0 1 = GAS VALVE #1 ON
1 1 = GAS VALVE #2 ON
2 1 = GAS VALVE #3 ON
3 1 = LIMIT #1 CLOSED (NOT TRIPPED)
4 1 = LIMIT #2 CLOSED
5 1 = LIMIT #3 CLOSED
6NA
7NA
17 L 23 H NA - - - INPUT STATUS BYTE #5
0 1 = FAN OVERLOAD CLOSED (NOT TRIPPED)
1 1 = FREEZE STAT CLOSED (NOT LOW TEMPERATURE)
2 1 = AIR PROVING CLOSED (AIR FLOW IS SENSED)
3NA
4NA
5 1 = VAV; 0 = CV
6 1 = CV / VAV OUT OF RANGE (FAULT CONDITION)
7 1 = LOW 24 VAC SUPPLY VOLTAGE
17 H 23 L NA - - - INPUT STATUS BYTE #6
0 1 = PROGRAM BUTTON PRESSED
1 1 = TEST / UP BUTTON PRESSED
2 1 = ALARMS / CHANGE BUTTON PRESSED
Continued on next page
TABLE - 6-2 - SIMPLICITY ELITE DATA MAP (CONT.)
