Please Do Not Return This Product To The Store. Call Us Directly! Our Trained Technicians Will Answer Your Questions and/or Ship Any Parts You May Need.
You can reach us Toll Free at 1-888-827-3667 for Consumer Assistance or online at www.wayne-dalton.com
www
.Wayne-Dalto
n.c
o
m
/access
Fin
d
out mo
r
e:
what’s
OPENING
your world
?
With
Z-
Wave
®
technolo
g
y
you can
control
your l
ights,
th
ermo
s
t
at and s
tart
your morning cof
fee,
all with the single
t
o
uc
h
o
f
a button.
P/N
33598
2
Z-
Wave
®
enabled
T
o
O
p
e
r
a
t
e
D
o
o
r
Press
Here
TO AVOID POSSIBLE SEVERE OR FATAL
INJURY, MANUALLY DISCONNECT THE
OPENER, USING THE EMERGENCY
DISCONNECT HANDLE PRIOR TO
PROGRAMMING REMOTE CONTROLS.
NOTE:
The opener can be activated by up
to six remote control devices (including
Wall Station, Transmitter, and Keyless Entry
Devices). If a seventh control is
programmed, the first of the program
controls will be overwritten and will no
longer activate the opener.
a. Pull the emergency disconnect handle to
the manual door operated position (lower
position).
b. On the front cover of the opener, press
and release the red program button; the
opener will beep once, indicating
activation of the program mode. The
opener will remain in program mode for
30 seconds. If at the end of 30 seconds
the opener has not learned an RF
device, the opener will beep once,
indicating the learn mode is no longer
active.
c. Press and hold the desired transmitter
button or wall station light button until
the opener beeps once. The transmitter
or wall station is now programmed.
No beeping response from the opener
during the transmitter or wall station
programming indicates a programming
failure. Repeat programming Steps a-c.
d. Return the emergency disconnect
handle to the motor operated position
(upper position).
NOTE: The first transmitter command
after programming will only move the
door through a six inch up/down cycle.
Normal door operations will occur on the
second use of the transmitter or wall
station.
Handle In Manual
Door Operated
Position
Red Program
Button
Motor in
Up Position
Handle In Motor
Operated
Position
a
b
c
d
LED
Light Button
WARNING
Tools Needed:
None
❉
Large Button
Programming Wireless Wall
Station(s) or Transmitter(s)
to Opener
