Please Do Not Return This Product To The Store. Call Us Directly! Our Trained Technicians Will Answer Your Questions and/or Ship Any Parts You May Need.
You can reach us Toll Free at 1-888-827-3667 for Consumer Assistance or online at www.wayne-dalton.com
IDRIVE
®
FOR TORQUEMASTER
®
INSTALLATION
S
1
S
2S3
S
4
Learn
Delete
Controls
S1
S2
S3
S4
Learn
Delete
Controls
Attaching Disconnect Cable
Attach the loose disconnect cable (located in
opener hardware bag) to the opener with the
“S” hook. Close both ends of the “S” hook
with pliers, to lock assembly together with
pliers.
Thread the disconnect cable (behind the
counterbalance cable) through the hole in
the right hand end bracket, and remove all
slack between opener and right end
bracket.
Close “S” Hook
Disconnect
Cable
S-Hook
Hole in Right
End Bracket
Hole in
End Bracket
Right Side of
End Bracket
Disconnect
Cable
S-Hook
Hole in Right
End Bracket
Hole in
End Bracket
Right Side of End
Bracket
6
Tools Needed:
Step Ladder
Pliers
Torquemaster
®
Torquemaster
®
Plus
