Z-8550A, 8560A
3. FUNCTION SETTINGS
7
Memory switch No. 47 - 60
No. Initial value Setting range Setting details
47 0 0 - 1
Operation during standing operation when AUTO function is on
0: When high-speed pedal turns on, sewing is momentarily stopped, and it
is resumed when pedal turns off.
1: Above function is disabled
This function is disabled when No. 49 is set to “1”.
48 0 0 - 1
Thread trimming pedal operation during standing operation after thread
trimming
0: Presser foot can be lifted and lowered
1: Above operation is disabled (only possible using presser foot lifter pedal)
49 0 0 - 1
Alternating operation of standing operation pedal and treadle
(Does not include operation of presser foot lifter pedal. In the case of
simultaneous operation, the standing operation pedal has priority.)
0: Treadle operation is disabled after standing operation pedal has been
used
1: Treadle operation is still enabled after standing operation pedal has been
used (alternating operation is possible)
51* 0 0 - 1
Correction sewing using actuator switch after thread trimming
0: Forbidden (switch operation disabled)
1: Possible
52 2 (stitches)
1 – 99
(stitches)
Number of slow start stitches
53* 10 (stitches)
0 - 100
(stitches)
Counting units for stitch counter display
0: No counting operation
1-100: Display counts down by the set number of stitches
54* 1 0 - 2
Stitch counter warning operation (when (!) icon is displayed)
0: Starting using treadle is always enabled
1: Starting using treadle prevented (thread trimming is possible when
treadle is depressed backward)
2: Operation using treadle fully prevented when treadle is returned to
neutral position and sewing stops
55 0 0 - 1
Operation when treadle is depressed backward or knee switch operation
when presser foot is lifted
0: Presser foot lifts when treadle is returned to neutral position
1: Presser foot lowers when treadle is returned to neutral position
56 0 0 - 1
Function for preventing accidental forward depression of the treadle to
cause the needle bar to move after the treadle has been depressed
backward and is then returned to the neutral position
0: Yes
1: None
57 0 0 - 1
Operation when treadle is depressed forward to the 1
st
step when the
presser foot is lifted
0: Presser foot is lowered
1: Presser foot is not lowered
58 0 0 - 1
Presser foot soft lift function
0: None
1: Yes (Settings for No. 59 and No. 60 are required.)
59
0 (ms) 0 - 150 (ms)
60 0 (ms) 0 - 99 (ms)
Presser foot soft lift timer setting
(When No. 58 is set to “1”)
* : Settings indicated with * are enabled after the power is turned off and then back on again.
Presser foot lifting
2247M
(Fully on)
