Z-8550A, 8560A
3. FUNCTION SETTINGS
6
Memory switch No. 31 - 46
No. Initial value Setting range Setting details
31 0 0 - 1
Stopping while start backtacking is in progress, and speed during start
backtacking
0: When the treadle is returned to the neutral position, start backtacking
ends, sewing stops and the sewing speed becomes the start backtacking
(constant) speed
1: When the treadle is returned to the neutral position, start backtacking can
be stopped before it is finished, and the speed during start backtacking
becomes the speed corresponding to the treadle depression amount (low
speed - start backtacking speed)
32 300 (ms) 10 - 990 (ms)
Fully on time for presser foot lifter solenoid
33 0 0 - 1
Fixed stitch function using actuator switch
0: None
1: Yes
35 0 0 - 1
Presser foot soft down mode
0: Automatic mode (Adjustment required using No. 39)
1: Manual mode (Adjustment required using No. 38)
36
180 (seconds)
(3 minutes)
0 - 240
(seconds)
Presser foot lift time
0: No timer function (is not lowered)
1-240: Presser foot is lowered after set time has elapsed
37 0 0 - 1
Model setting for automatic presser foot lifter
0: Solenoid type (Duty while chopping can be varied using No. 115)
1: Pneumatic type (Duty while chopping can be varied using No. 116)
38 40 (ms) 20 - 120 (ms)
Delay time from presser foot lowering command until presser foot lifter
solenoid momentarily turns on (only enabled when No. 35 is set to “0”)
39 12 10 - 12
Sensing voltage constant from presser foot lowering command until presser
foot lifter solenoid momentarily turns on (only enabled when No. 35 is set to
“0”
If it is set to “10”, the response will be fastest and the operating noise will be
loudest.
40 0 0 - 1
Operation when presser foot is lifted and lowered using knee switch
This setting is only enabled when DIP switch No. 1 is set to “OFF”.
0: Presser foot cannot be lifted or lowered by depressing the treadle
backward
1: The above operation is possible.
41 0 0 - 1
Presser foot lifting after treadle is returned to neutral position so sewing
stops, and is then depressed backward to the 1
st
step
0: Possible
1: Not possible
When No. 42 is set to “1”, this function operates as though set to “0”.
42 0 0 - 1
Operation when treadle is depressed backward
0: Thread trimming operation
1: Thread trimming operation is disabled (presser foot is lifted when treadle
is depressed backward)
(The default setting for standard specifications is “1”, and the default setting
for other specifications is “0”.)
44 0 0 - 2
Operation when standing operation variable speed pedal is on
0:Sewing speed is in accordance with treadle depression amount
1: Operation is at the sewing speed set by the speed bar key (constant
speed)
2: Operation is at end backtacking speed
45 80 (ms) 0 - 500 (ms)
Delay time for motor to start when standing operation pedal turns on.
46 0 0 - 1
Operation during standing operation when AUTO function is on
0: Sewing stops before finished when presser lifter pedal turns on
(momentary stop operation)
1: Above function is disabled
