Z-8550A, 8560A
3. FUNCTION SETTINGS
4
3-2. List of memory switch settings
Memory switch No. 0 - 15
No. Initial value Setting range Setting details
0 0 (degrees)
-10 - 10
(degrees)
Needle up stop position setting
Higher Lower
1 0 (degrees)
-10 - 10
(degrees)
Needle down stop position setting
Higher Lower
2 0 0 - 1
Depressing treadle forward when treadle is depressed backward (thread
trimming)
0: Disabled (Enabled after treadle is returned to neutral position and then
depressed forward)
1: Enabled
3 1 0 - 1
Power supply voltage drop check (reset detection) function
0: None
1: Enabled, [Err 95] displayed when voltage drops.
4 0 0 - 1
Buzzer (electronic sound) during panel operation
0: Yes
1: None
5 0 -
[Do not change this setting.]
6 0 0 - 1
Piercing force boosting operation
0: Yes
1: None
7 0 0 - 1
End backtacking speed
0: Limited by speed bar key setting
1: Not limited by speed bar key setting
9 0 0 - 1
End backtacking sewing speed
0: Speed can be set independently from start backtacking speed
1: Speed is set to start backtacking speed
12 0 0 - 1
Presser foot condition when treadle is returned to neutral position after
thread trimming
0: Presser foot is lowered (it is not lowered when DIP switch 1 is OFF)
1: Presser foot is not lowered
13 0 0 - 1
Presser foot condition when operation stops at the neutral treadle position
0: Presser foot is not lifted
1: Presser foot is lifted
14 0 0 - 1
Actuator function
0: Operates as a reverse stitch switch during sewing, and as a correction
stitch switch when sewing is stopped
1: Thread trimming switch
15 0 0 - 1
Deceleration stop control when treadle is returned to neutral position
0: Deceleration stop control without single stitch advance
1: Above control is not carried out
