TABLE 20: COOLING CAPACITIES FOR DJ300 AT 95°F
RETURN AIR OUTDOOR AMBIENT TEMPERATURE (°F): 95
CFM
WB
TEMP °F
GROSS
CAPACITY
1
(MBH)
INPUT
POWER
2
(kW)
GROSS SENSIBLE CAPACITY
1
(MBH)
(RETURN AIR DRY BULB TEMP. - (°F) )
86 83 80 77 74 71 68
7500
72
324.4 25.42 191.5 170.2 148.8 127.4 106.0 #N/A #N/A
67
305.5 24.73 245.9 224.5 203.1 181.7 160.4 139.0 117.6
62
301.1 24.23 295.5 274.2 252.8 231.4 210.0 188.6 167.2
57
292.2 24.07 292.2 277.1 255.7 234.3 212.9 191.5 170.1
8750
72
326.8 25.46 207.5 182.3 157.0 131.7 106.4 #N/A #N/A
67
307.7 24.76 264.9 239.6 214.4 189.1 163.8 138.5 113.3
62
303.3 24.26 300.5 289.8 266.7 241.5 216.2 190.9 165.7
57
294.3 24.10 294.3 286.7 269.8 244.5 219.3 194.0 168.7
10000
72
329.1 25.49 223.5 194.4 165.2 136.1 106.9 #N/A #N/A
67
309.9 24.79 283.9 254.7 225.6 196.4 167.3 138.1 108.9
62
305.5 24.29 305.5 305.5 280.7 251.6 222.4 193.2 164.1
57
296.4 24.13 296.4 296.4 283.9 254.8 225.6 196.5 167.3
11250
72
336.1 25.73 238.9 205.7 172.5 139.3 106.1 #N/A #N/A
67
316.4 25.02 302.0 268.8 235.5 202.3 169.1 135.9 102.7
62
311.9 24.52 311.9 311.9 293.1 259.9 226.7 193.5 160.3
57
302.7 24.36 302.7 302.7 296.5 263.2 230.0 196.8 163.6
12500
72
343.1 25.96 254.3 217.1 179.8 142.5 105.3 #N/A #N/A
67
323.0 25.25 320.0 282.8 245.5 208.2 171.0 133.7 96.5
62
318.4 24.74 318.4 318.4 305.5 268.2 231.0 193.7 156.5
57
309.0 24.58 309.0 309.0 309.0 271.7 234.4 197.2 159.9
1. The capacities are gross ratings. For net capacity, deduct the supply air blower motor heat, MBH = 3.415 x kW. Refer to the appro-
priate blower performance table for the kW of the supply air blower motor.
2. These ratings include condenser fan motor and compressor motor power but not the supply air blower motor power.
