036-21410-001-A-0502
Unitary Products Group 13
TABLE 4: COOLING CAPACITIES FOR DJ180 AT 85°F
RETURN AIR OUTDOOR AMBIENT TEMPERATURE (°F): 85
CFM
WB
TEMP °F
GROSS
CAPACITY
1
(MBH)
INPUT
POWER
2
(kW)
GROSS SENSIBLE CAPACITY
1
(MBH)
(RETURN AIR DRY BULB TEMP. - (°F) )
86 83 80 77 74 71 68
4500
72
210.2 12.36 121.0 108.2 95.3 82.5 69.7 #N/A #N/A
67
193.0 11.97 151.5 138.6 125.8 113.0 100.2 87.3 74.5
62 177.6 11.68 177.6 167.6 154.8 141.0 129.1 116.3 103.5
57
182.7 11.62 182.1 169.2 156.4 143.6 130.7 117.9 105.1
5250
72
216.7 12.47 133.6 118.4 103.3 88.1 72.9 #N/A #N/A
67 198.9 12.08 166.6 151.4 136.3 121.1 105.9 90.8 75.6
62
183.1 11.78 183.1 178.1 167.6 152.5 137.3 122.1 107.0
57
188.4 11.72 188.0 181.6 169.4 154.2 139.0 123.9 108.7
6000
72
223.2 12.58 146.2 128.7 111.2 93.7 76.2 #N/A #N/A
67
204.9 12.19 181.7 164.2 146.7 129.2 111.7 94.2 76.7
62
188.6 11.89 188.6 188.6 180.5 163.0 145.5 128.0 110.5
57 194.0 11.83 194.0 194.0 182.4 164.9 147.4 129.9 112.4
6750
72
229.7 12.61 157.8 137.9 118.0 98.1 78.1 #N/A #N/A
67
210.8 12.21 195.6 175.6 155.7 135.8 115.9 95.9 76.0
62 194.0 11.91 194.0 194.0 190.0 170.1 150.1 130.2 110.3
57
199.6 11.86 199.6 199.6 193.6 173.6 153.7 133.8 113.9
7500
72
236.1 12.64 169.5 147.2 124.8 102.5 80.1 #N/A #N/A
67 216.7 12.24 209.4 187.1 164.7 142.4 120.0 97.7 75.3
62
199.5 11.94 199.5 199.5 199.5 177.1 154.8 132.4 100.1
57
205.2 11.88 205.2 205.2 204.8 182.4 160.1 137.7 115.3
1. The capacities are gross ratings. For net capacity, deduct the supply air blower motor heat, MBH = 3.415 x kW. Refer to the appro-
priate blower performance table for the kW of the supply air blower motor.
2. These ratings include condenser fan motor and compressor motor power but not the supply air blower motor power.
