TABLE 17: COOLING CAPACITIES FOR DJ240 AT 115°F
RETURN AIR OUTDOOR AMBIENT TEMPERATURE (°F): 115
CFM
WB
TEMP °F
GROSS
CAPACITY
1
(MBH)
INPUT
POWER
2
(kW)
GROSS SENSIBLE CAPACITY
1
(MBH)
(RETURN AIR DRY BULB TEMP. - (°F) )
86 83 80 77 74 71 68
6000
72
230.8 21.72 142.8 125.7 108.6 91.5 74.4 #N/A #N/A
67
213.4 21.43 181.2 164.1 147.0 129.9 112.8 95.7 78.6
62
190.2 21.09 190.2 188.9 171.8 154.7 137.6 120.5 103.4
57
202.2 21.28 202.2 198.2 181.1 164.0 146.9 129.8 112.7
7000
72
236.4 21.79 157.8 137.5 117.3 97.1 76.9 #N/A #N/A
67
218.5 21.50 199.2 179.0 158.8 138.6 118.4 98.1 77.9
62
194.8 21.16 194.8 194.1 185.6 165.4 145.1 124.9 104.7
57
207.0 21.35 207.0 205.1 195.7 175.4 155.2 135.0 114.8
8000
72
241.9 21.87 172.7 149.4 126.0 102.7 79.4 #N/A #N/A
67
223.6 21.58 217.3 193.9 170.6 147.3 123.9 100.6 77.3
62
199.4 21.24 199.4 199.4 199.4 176.0 152.7 129.4 106.1
57
211.9 21.43 211.9 211.9 210.2 186.9 163.5 140.2 116.9
8700
72
250.6 22.15 187.0 161.3 135.6 110.0 84.3 #N/A #N/A
67
231.7 21.85 228.5 209.3 183.6 157.9 132.2 106.6 80.9
62
206.6 21.51 206.6 206.6 206.6 180.9 155.2 129.5 103.9
57
219.5 21.70 219.5 219.5 218.7 193.0 167.3 141.7 116.0
9400
72
259.4 22.43 201.3 173.3 145.2 117.2 89.2 #N/A #N/A
67
239.7 22.13 239.7 224.6 196.6 168.6 140.5 112.5 84.5
62
213.8 21.78 213.8 213.8 213.8 185.7 157.7 129.7 101.7
57
227.2 21.98 227.2 227.2 227.2 199.2 171.1 143.1 115.1
1. The capacities are gross ratings. For net capacity, deduct the supply air blower motor heat, MBH = 3.415 x kW. Refer to the appro-
priate blower performance table for the kW of the supply air blower motor.
2. These ratings include condenser fan motor and compressor motor power but not the supply air blower motor power.
