TABLE 18: COOLING CAPACITIES FOR DJ240 AT 125°F
RETURN AIR OUTDOOR AMBIENT TEMPERATURE (°F): 125
CFM
WB
TEMP °F
GROSS
CAPACITY
1
(MBH)
INPUT
POWER
2
(kW)
GROSS SENSIBLE CAPACITY
1
(MBH)
(RETURN AIR DRY BULB TEMP. - (°F) )
86 83 80 77 74 71 68
6000
72
217.6 23.35 139.1 122.0 104.9 87.8 70.7 #N/A #N/A
67
201.4 23.23 175.7 158.6 141.5 124.4 107.3 90.2 73.1
62
177.7 22.82 177.7 177.7 165.8 148.7 131.6 114.5 97.4
57
192.7 22.93 192.7 190.8 173.7 156.5 139.4 122.3 105.2
7000
72
222.2 23.43 153.1 132.8 112.6 92.4 72.2 #N/A #N/A
67
205.6 23.31 192.3 172.1 151.9 131.7 111.4 91.2 71.0
62
181.5 22.90 181.5 181.5 178.0 157.8 137.6 117.4 97.1
57
196.8 23.01 196.8 195.8 186.4 166.2 146.0 125.7 105.5
8000
72
226.8 23.51 167.0 143.7 120.3 97.0 73.7 #N/A #N/A
67
209.9 23.39 208.9 185.6 162.3 138.9 115.6 92.3 68.9
62
185.2 22.98 185.2 185.2 185.2 166.9 143.5 120.2 96.9
57
200.8 23.09 200.8 200.8 199.1 175.8 152.5 129.1 105.8
8700
72
237.2 23.74 182.7 157.0 131.3 105.7 80.0 #N/A #N/A
67
219.5 23.61 219.0 202.8 177.1 151.5 125.8 100.1 74.4
62
193.7 23.19 193.7 193.7 193.7 170.6 144.9 119.2 93.6
57
210.0 23.30 210.0 210.0 209.2 183.5 157.8 132.1 106.5
9400
72
247.6 23.96 198.4 170.4 142.4 114.3 86.3 #N/A #N/A
67
229.1 23.84 229.1 220.0 192.0 164.0 136.0 107.9 79.9
62
202.3 23.41 202.3 202.3 202.3 174.3 146.3 118.2 90.2
57
219.2 23.52 219.2 219.2 219.2 191.2 163.2 135.1 107.1
1. The capacities are gross ratings. For net capacity, deduct the supply air blower motor heat, MBH = 3.415 x kW. Refer to the appro-
priate blower performance table for the kW of the supply air blower motor.
2. These ratings include condenser fan motor and compressor motor power but not the supply air blower motor power.
