11.3. Wiring transmission cables
Wiring method, address setting method and permissible wiring length differ according to and whether or not you are using transmission booster. Check
permissible wiring length before wiring.
A may be required depending on the number of indoor units.
Item 4 “Wiring examples” gives typical wiring examples (a-c).
a. System using remote controller (1 outdoor unit)
b. System using remote controller (system operated as a group among multiple refrigerant systems)
c. System using power supply extension unit for transmission booster (combination of systems a-b)
1 Connecting a transmission booster
A transmission booster (RP) is required when the number of connected indoor unit models in a cooling system exceeds the number of models specified
in the chart below.
* The maximum number of units that can be controlled is determined by the indoor unit model, the type of remote controller and their capabilities.
200 or lower
200 or higher
Remote controller PAR-F 25MA
Prior to Ver. E After Ver. F
16 (32) 20 (40)
16 (32) 16 (32)
(*1)
Capability of the
connected indoor units
Remote controller type
Number of connected indoor units that can be
connected without a RP.
The number of indoor units and the total number of remote controllers is displayed within the parenthesis ( ).
*1 If even one unit that is higher than 200 exists in the cooling system, the maximum capacity will be “200 or higher”.
2 Name, code and possible unit connections
Name Code Possible unit connections
Outdoor unit
Indoor unit
Remote controller
Other
Variable capacity unit controller
Constant capacity unit controller
Indoor unit controller
Remote controller (*1)
Transmission booster unit
–
1 unit per 1 OC.
2 to 32 units per 1 OC (*1).
2 units maximum per group.
0 to 1 unit per 1 OC (*1).
OC
OS
IC
RC
RP
*1 A transmission booster (RP) may be required depending on the number of connected indoor unit controllers.
3 Types of control cables
(1) Wiring transmission cables
• Types of transmission cables
Shielding wire CVVS or CPEVS
• Cable diameter
More than 1.25 mm
2
• Maximum wiring length within 200 m
(2) Remote control cables
Kind of remote control cable 2-core cable (unshielded)
Cable diameter 0.5 to 0.75 mm
2
Remarks
When 10 m is exceeded, use cable with the same
specifications as (1) Transmission line wiring.
4 Wiring examples
Typical wiring examples are shown on pages
28
to
32
. (Wiring examples A ~ C)
