16. Function of Remote Controller
TIMER
ON
HOUR
WARM
MIN
COOL
SWING SLEEP
OFF
LOW
MED
HIGH
AUTO
COOL
FAN
HEAT
FAN
SWING SLEEP
COOL HEAT ON OFF
TIMER
FAN
HR.
SWING SLEEP
COOL
CLOCK
AUTO
T
E
M
P
ON / OFF
MODE
FAN
FAN
SWING SLEEP
COOL HEAT ON OFF
TIMER
HR.
CLOCK
AUTO
LCD DISPLAYS
ON/OFF
Press button to set timer mode.
TRANSMISSION SOURCE
Used for sending control signal to
the air conditioning unit.
FAN BUTTON
Press button to select low, Medium,
High or Auto speed.
MODE BUTTON
Press button to select Cool, Fan or
Heat mode.
ON/OFF BUTTON
Pressing this button will turn the air-
conditioning unit on or off.
LCD DISPLAY
SWING BUTTON
Air distributor in all modes.
SLEEP BUTTON
Sleep mode will automatically
adjust temperature and save
energy when you are sleeping.
HOUR BUTTON
Press button to increase the time
1 hour in each step (24 hours).
MINUTE BUTTON
Press button to increase the time
10 minutes in each step in timer
mode and 1 minute in each step
in real time clock.
WARM BUTTON
Press button to increase
temperature 1°C in each step
(Max. 30°C).
COOL BUTTON
Press button to decrease
temperature 1°C in each step
(Min. 15°C).
MODE
FAN, COOL, HEAT
SIGNAL SENDING
SET TEMP
SLEEP
SWING
FAN SPEED
AUTO
LOW-MED-HI
TIMER ON/OFF
CLOCK
HOUR & MINUTE
For VC/VD Chassis Model
