Ceiling & Floor, Ceiling Suspended (50Hz, R22) 47
10. Performance Data
Model No.: LV-C(H)608LLA(B)0, LV-C608LLA1
Notes:
1. All capacites are net, evaporator fan motor heat is deducted. 2. DB=Dry Bulb Temperature(°F), WB=Wet Bulb Temperature(°F)
3. TC=Total cooling capacity(Unit:kBtu/h) 4. SHC=Sensible heat capacity(Unit:kBtu/h)
5. PI=Power Input(Comp.+ indoor fan motor+outdoor fan motor) (kW)
Model No.: LV-C(H)368KLA(B)0
Model No.: LV-C(H)488LLA(B)0, LV-C488LLA1
Indoor DB (°F)
75
80
85
90
Outdoor DB (°F) 85 95 105
Indoor WB (°F) 61 67 73 61 67 73 61 67
43.3 34.0 4.19 47.9 25.8 4.32 51.5 11.4 4.40 41.8 34.7 4.63 46.2 26.3 4.78
45.2 39.1 4.20 48.7 32.3 4.33 51.5 21.1 4.41 43.6 39.8 4.64 47.0 32.9 4.79
46.9 42.8 4.21 49.4 38.9 4.35 51.3 29.2 4.43 45.2 43.7 4.66 47.7 39.6 4.80
48.4 45.1 4.23 50.0 43.2 4.36 51.0 35.6 4.44 46.7 46.0 4.67 48.2 44.0 4.82
49.6 11.6 4.86 40.3 33.8 4.96 44.6 25.6 5.11
49.7 21.5 4.88 42.0 38.8 4.97 45.4 32.1 5.13
49.5 29.8 4.89 43.6 42.5 4.99 46.0 38.6 5.14
49.2 36.3 4.91 45.1 44.8 5.00 46.5 42.9 5.16
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
TC SHC PI TC SHC PI TC SHC PI
Indoor DB (°F)
75
80
85
90
Outdoor DB (°F) 105 115 125
Indoor WB (°F) 73 61 67 73 61 67 73
47.9 11.3 5.21 38.0 32.9 5.24 42.0 24.9 5.40 45.2 11.0 5.50
47.9 21.0 5.22 39.7 37.8 5.26 42.8 31.2 5.42 45.2 20.4 5.52
47.8 29.0 5.24 41.2 41.2 5.27 43.4 37.6 5.44 45.1 28.3 5.54
47.5 35.4 5.25 42.5 42.5 5.29 43.9 41.8 5.45 44.8 34.4 5.55
35.2 31.4 5.48 38.9 23.8 5.65 41.9 10.5 5.76
36.8 36.1 5.49 39.6 29.8 5.67 41.9 19.5 5.77
38.1 38.1 5.51 40.2 35.9 5.68 41.8 27.0 5.79
39.4 39.4 5.53 40.7 39.8 5.70 41.5 32.8 5.81
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
Indoor DB (°F)
75
80
85
90
Outdoor DB (°F) 85 95 105
Indoor WB (°F) 61 67 73 61 67 73 61 67
33.2 27.9 3.03 36.7 21.2 3.13 39.4 9.3 3.19 32.0 28.5 3.35 35.4 21.6 3.46
34.6 32.1 3.04 37.3 26.5 3.14 39.4 17.4 3.20 33.4 32.7 3.36 36.0 27.0 3.47
35.9 35.2 3.05 37.9 31.9 3.15 39.3 24.0 3.21 34.6 34.6 3.37 36.5 32.5 3.48
37.1 37.0 3.06 38.3 35.4 3.16 39.1 29.2 3.22 35.8 35.8 3.38 36.9 36.1 3.49
38.0 9.5 3.52 30.9 27.7 3.59 34.1 21.0 3.70
38.0 17.7 3.53 32.2 31.9 3.60 34.7 26.3 3.71
37.9 24.5 3.54 33.4 33.4 3.61 35.2 31.7 3.73
37.7 29.8 3.56 34.5 34.5 3.62 35.6 35.2 3.74
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
TC SHC PI TC SHC PI TC SHC PI
Indoor DB (°F)
75
80
85
90
Outdoor DB (°F) 105 115 125
Indoor WB (°F) 73 61 67 73 61 67 73
36.7 9.3 3.77 29.1 27.0 3.80 32.2 20.4 3.92 34.6 9.0 3.99
36.7 17.2 3.78 30.4 30.4 3.81 32.8 25.6 3.93 34.6 16.8 4.00
36.6 23.8 3.79 31.5 31.5 3.82 33.3 30.8 3.94 34.5 23.2 4.01
36.4 29.0 3.81 32.6 32.6 3.83 33.6 33.6 3.95 34.3 28.2 4.02
27.0 25.8 3.97 29.8 19.5 4.09 32.1 8.6 4.17
28.2 28.2 3.98 30.4 24.4 4.11 32.1 16.0 4.18
29.2 29.2 3.99 30.8 29.4 4.12 32.0 22.1 4.19
30.2 30.2 4.00 31.1 31.1 4.13 31.8 27.0 4.21
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
Indoor DB (°F)
75
80
85
90
Outdoor DB (°F) 85 95 105
Indoor WB (°F) 61 67 73 61 67 73 61 67
47.9 37.7 4.96 53.0 28.5 5.11 56.9 12.6 5.21 46.2 38.4 5.48 51.1 29.1 5.65
50.0 43.3 4.97 53.9 35.7 5.13 57.0 23.4 5.22 48.2 44.1 5.50 52.0 36.4 5.67
51.9 47.4 4.99 54.7 43.0 5.14 56.8 32.4 5.24 50.0 48.3 5.51 52.8 43.8 5.69
53.6 49.9 5.00 55.3 47.8 5.16 56.4 39.4 5.26 51.7 50.9 5.53 53.3 48.7 5.70
54.9 12.8 5.76 44.6 37.4 5.87 49.3 28.3 6.05
54.9 23.8 5.78 46.5 43.0 5.88 50.2 35.5 6.07
54.8 33.0 5.79 48.3 47.1 5.90 50.9 42.7 6.09
54.5 40.2 5.81 49.9 49.6 5.92 51.5 47.5 6.11
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
TC SHC PI TC SHC PI TC SHC PI
Indoor DB (°F)
75
80
85
90
Outdoor DB (°F) 105 115 125
Indoor WB (°F) 73 61 67 73 61 67 73
53.0 12.5 6.16 42.1 36.4 6.20 46.5 27.6 6.40 50.0 12.2 6.52
53.0 23.2 6.18 43.9 41.8 6.22 47.4 34.5 6.42 50.0 22.6 6.54
52.9 32.1 6.20 45.6 45.6 6.24 48.0 41.6 6.44 49.9 31.3 6.56
52.6 39.1 6.22 47.1 47.1 6.26 48.6 46.2 6.46 49.6 38.1 6.58
39.0 34.7 6.48 43.1 26.3 6.69 46.3 11.6 6.81
40.7 39.9 6.50 43.9 32.9 6.71 46.3 21.6 6.83
42.2 42.2 6.52 44.5 39.7 6.73 46.2 29.8 6.85
43.6 43.6 6.54 45.0 44.1 6.75 45.9 36.3 6.87
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
