Performance
Data Security Wall Fin
Table PD-6 — Copper/Aluminum Elements — Watts/Meter
Steam
Rating Hot Water (Ave.)
Copper/Aluminum Elements with Fully Perforated Enclosures 102°C 104°C99°C93°C88°C82°C77°C71°C66°C60°C54°C
Tube Fin Size Fins/ Encl. Tiers & Mtg. Height Factor Factor
Size Inches Foot Type Centers Inches 1.00 1.05 0.95 0.86 0.78 0.69 0.61 0.53 0.45 0.40 0.33
S12-SF 1 406 1260 1250 1130 1030 930 830 730 630 540 480 390
S18-SF 1 559 1490 1300 1180 1070 970 860 760 650 560 500 410
19 mm 108 x 92 131 S18-SF 2-152 mm 559 2180 2250 2040 1850 1670 1480 1310 1130 960 860 710
F12-SF 1 406 1150 1150 1040 940 860 760 670 580 490 440 370
F18-SF 1 559 1350 1180 1070 970 870 780 680 600 510 450 380
F18-SF 2-152 mm 559 2000 2060 1860 1680 1530 1360 1190 1040 880 790 640
S12-SF 1 406 1370 1360 1230 1120 1010 890 790 690 590 520 430
S18-SF 1 559 *1720 1410 1280 1150 1050 930 820 710 610 540 440
19 mm 108 x 92 164 S18-SF 2-152 mm 559 2310 2410 2180 1980 1790 1590 1400 1220 1040 920 760
F12-SF 1 406 1300 1280 1160 1050 950 850 740 640 550 490 400
F18-SF 1 559 1550 1300 1180 1070 970 860 760 650 560 500 410
F18-SF 2-152 mm 559 2200 2300 2090 1880 1710 1510 1340 1160 990 870 720
S12-SF 1 406 1430 1440 1310 1180 1080 950 840 730 620 550 450
S18-SF 1 559 1660 1490 1360 1220 1110 980 870 750 640 570 470
25 mm 108 x 108 131 S18-SF 2-152 mm 559 2300 2590 2340 2110 1920 1700 1500 1310 1110 980 810
F12-SF 1 406 1310 1330 1190 1090 980 870 770 660 570 500 410
F18-SF 1 559 1490 1350 1210 1100 1000 880 780 670 580 510 420
F18-SF 2-152 mm 559 2200 2470 2240 2030 1840 1620 1430 1250 1060 940 780
S12-SF 1 406 1510 1480 1350 1210 1110 970 870 750 630 570 470
S18-SF 1 559 1900 1550 1390 1270 1140 1020 890 780 660 590 480
25 mm 108 x 108 164 S18-SF 2-152 mm 559 2170 2610 2360 2140 1940 1720 1520 1320 1120 1000 820
F12-SF 1 406 1410 1390 1260 1140 1040 910 810 700 600 530 440
F18-SF 1 559 1700 1430 1300 1170 1070 940 840 720 620 550 450
F18-SF 2-152 mm 559 2070 2480 2250 2040 1850 1630 1440 1250 1070 940 780
S12-SF 1 406 1410 1410 1280 1150 1050 930 820 710 610 540 440
S18-SF 1 559 1630 1470 1340 1210 1100 970 860 740 630 560 460
32 mm 108 x 108 131 S18-SF 2-152 mm 559 *2260 2550 2300 2090 1890 1670 1480 1290 1090 970 800
F12-SF 1 406 1290 1290 1170 1060 960 850 750 650 560 490 400
F18-SF 1 559 1470 1330 1190 1090 980 870 770 660 570 500 410
F18-SF 2-152 mm 559 2160 2430 2200 1990 1810 1600 1410 1230 1040 920 770
S12-SF 1 406 *1480 1450 1320 1190 1080 950 850 730 620 560 460
S18-SF 1 559 *1860 1520 1370 1240 1120 1000 880 770 650 580 480
32 mm 108 x 108 164 S18-SF 2-152 mm 559 2130 2580 2330 2110 1910 1690 1500 1300 1110 980 810
F12-SF 1 406 1390 1370 1240 1120 1020 900 800 690 590 520 430
F18-SF 1 559 1670 1410 1280 1150 1050 930 820 710 610 540 440
F18-SF 2-152 mm 559 2030 2440 2210 2000 1820 1610 1420 1230 1050 930 770
1. *I = B = R Rating on Assemblies as marked.
2. Mounting Height is the dimension from the floor to the top of the enclosure to obtain listed capacities.
3. Two-tier applications can only be used with 457 mm high enclosures installed on 152 mm center lines.
Finned Tube Radiation
Model S and F — Security Enclosures Fully Perforated
Capacity Data
