SMC sierra monitor corporation Sentry Instruction Manual - Version 6
LIST OF TABLES
Page: 123
INTERNAL NOTES FOR THIS MANUAL
Author:
1. Gordon Arnold - July 1992
2. Gordon Arnold - November 1995
General:
1. This manual is a re-write of the Version 4.0 Instruction and Service manuals for Sentry systems. Changes
implemented are to comply with FM approval requirements and to update or correct sections which have
been obsoleted by time.
2. This manual is updated (1995) to incorporate changes due to Version 6.X
Publishing:
1. Formatting is for HPDWNB2P
2. Format is for double side printing for 3 hole binders or spiral bind.
3. All appendices are to be included in all copies of the manual.
4. WARNING: WORD 6.0 AND ORIGINAL RELEASE OF WORD 7.0 HAVE A BUG WHICH WILL
CAUSE SHRINKING OF FIGURE CROSS REFERENCES. USE ONLY WORD 6.0a (UPDATED ON
GORDON ARNOLD’S COMPUTER 11/95) OR USE AN UPDATED 7.0 SYSTEM.
ALWAYS CHECK CONTENT, INDEX AND LISTS FOR ACCURATE PAGE NUMBERS BEFORE RUNNING
COPIES.
PHYSICAL CUT AND PASTE REQUIRED TO COMPLETE SMALL FIGURES.
FOR FULL PAGE FIGURES OBTAIN ORIGINAL SUBMITTAL DRAWINGS FROM DRAFTING, THEN USE
UPDATED FILE FIGRTAGS.DOC TO PRINT LABELS INTO LEGEND BLOCK.
Changes:
1. July 13, 1992 - First distributed draft.
2. August 1992 - Final FM approval changes including FM Logo
3. NOTE: No further changes unless approved by FM
4. Update for FM approval 5/95 THRU 11/95
5. FM approval 11/95 uses draft of Version 6 manual.
6. Final Version 6 Manual to be submitted to FM in December 1995.
7. Added drawings to electronic version in 2001.
8. Figures captions were corrupted.
Manual Writing Notes:
1. In Version 6.0 all specifications were correlated with sales latest literature.
