3. As you proceed with the assembly, installation, and adjustment steps in this manu-
al you may nd it helpful to refer back to this illustration of a completed installation.
(See Figure C.)
(54): Header Bracket (31): Housing
(66): Idler Pulley Seat (34): Light Cover
(45): Trolley (43): Manual Release Rope & Handle
(35): Rail (49): Curved Door Arm
(59): Chain (46): Straight Door Arm
(28): Hanging Bracket (50): Door Bracket
(9): Power Cord (54): Header Bracket
