19
A
Bobbin Winding
NOTE:
Set the speed control slider at its fastest position for
bobbin winding.
q Upper thread guide (A)
w Upper thread guide (B)
e Bobbin winding tension disk
r Bobbin winder spindle
t Bobbin winder stopper
z Draw the thread from the spool.
x Guide the thread around the upper thread guide (A) q,
upper thread guide (B) w and bobbin winding tension
disk e.
c Insert the thread through the hole in the bobbin,
threading from the inside to the outside. Put the
bobbin on the bobbin winder spindle r.
v Push the bobbin winder spindle r to the right. The
LCD screen shows A.
• Additional spool pin
y Spool
u Additional spool pin
i Spool pin felt
o Spool stand
!0 Spool pin hole
The additional spool pin u is for bobbin winding, without
unthreading the machine, and for twin needle sewing.
Insert the additional spool pin u into spool stand o and
the hole !0.
Place the felt i and a spool y on the pin as illustrated.
z
w
q
e
x
!0
r
c
v
t
b
n
y
i
u
o
!0
b With the free end of the thread held in your hand,
depress the foot control. Stop the machine when
the bobbin has made a few turns, and cut the
thread close to the hole on the bobbin.
n Depress the foot control again. When the bobbin is
fully wound, it will stop automatically. Return the
bobbin to its original position by moving the spindle
to the left, and cut the thread as shown.
