ProduCt SPeCifiCationS
ProduCt SPeCifiCationS
SS-CPH90-150 www.goodmanmfg.com 5
ProduCt SPeCifiCationS — 10 tonS
CPH120
***3B***
CPH120
***4B***
CPH120
***7B***
Cooling Capacity
Total BTU/h 118,000 118,000 118,000
Sensible BTU/h 87,300 87,300 87,300
EER / IEER 11.5 / 11.5 11.5 / 11.5 11.5 / 11.5
Decibels 83 83 83
Heating Capacity
BTU/h (47° F) 120,000 120,000 120,000
COP (47°F) 3.4 3.4 3.4
BTU/h (17° F) 56,000 56,000 56,000
COP (17°F) 2.4 2.4 2.4
Evaporator Motor / Coil
Motor Type Belt Drive Belt Drive Belt Drive
Indoor Nominal CFM 4,000 4,000 4,000
Indoor motor FLA (Cooling) 7.8 3.9 2.5
Horsepower - RPM 2.0/1725 2.0/1725 2.0/1725
Piston Size (Cooling) 0.086 0.086 0.086
Expansion Device Orice Orice Orice
Filter Size (4) 16" x 24" x 2" (4) 16" x 24" x 2" (4) 16" x 24" x 2"
Drain Size (NPT) ¾" ¾" ¾"
R-410A Refrigerant Charge Cir #1 & #2 (oz.) 225 / 225 225 / 225 225 / 225
Evaporator Coil Face Area (²) 10.2 10.2 10.2
Rows Deep/ Fins per Inch 4 / 14 4 / 14 4 / 14
Belt Drive Evap Fan Data
# of Wheels (D x W) (1) 15" x 15" (1) 15" x 15" (1) 15" x 15"
Motor Sheave / Blower Sheave VL40 / AK74 VL40 / AK74 VL40 / AK74
Belt AX51 AX51 AX51
Condenser Fan / Coil
Quanty of Condenser Fan Motors 2 2 2
Horsepower - RPM ⅓ - 1,075 ⅓ - 1,075 ⅓ - 1,125
Fan Diameter / # Fan Blades 22 / 3 22 / 3 22 / 3
Outdoor Nominal CFM 7,200 7,200 7,200
Face Area (²) 32.4 32.4 32.4
# Coils / Rows Deep - Fins per Inch 2 / 2 - 22 2 / 2 - 22 2 / 2 - 22
Piston Size (Heang) 0.064 0.064 0.064
Compressor
Quanty / Type / Stage 2 / Scroll / 1 2 / Scroll / 1 2 / Scroll / 1
Compressor RLA / LRA ea. 16 / 110.0 7.8 / 52.0 5.7 / 38.9
Electrical Data
Voltage/Phase/ Frequency 208-230/3/60 460/3/60 575/3/60
Belt-Driven Standard Max Stac 1.4 1.4 1.4
Outdoor Fan RLA ea. 2.40 1.20 0.90
Total Unit Amps 45 22 16
Min. Circuit Ampacity¹ 49 24 17
Max. Overcurrent Protecon (amps)² 60 30 20
Entrance Power Supply & Control Voltage Locang Dimple
Operating Weight (lbs) 1285 1285 1285
Ship Weight (lbs) 1310 1310 1310
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
