ProduCt SPeCifiCationS
ProduCt SPeCifiCationS
22 www.goodmanmfg.com SS-CPH90-150
Heat kit eleCtriCal data — 10 tonS
kw CorreCtion faCtor
kW Correction Factor (for 1- & 3-Phase Units)
Supply Voltage 240 230 220 210 208
Correcon Factor 1 0.93 0.82 0.78 0.76
kW Correction Factor for 480V Units
Actual Voltage 460 440 430
Correcon Factor 0.92 0.84 0.8
For other voltage use voltage² / 480²
kW Correction Factor for 575V Units
Supply Voltage 560 550 540
Correcon Factor 0.95 0.91 0.88
Multiply rated kW by correction factor to get actual kW
minimum airflow for eleCtriC Heat
Heater Size (kW)
Min. CFM
Down-shot
Min. CFM
Horizontal
15 4,000 4,000
30 4,000 4,000
43 4,000 4,000
Model and
Heat Kit Usage
MCA¹ at
208 / 240V
MOP² (amps)
at 208 / 240V
Actual kW
at 240V
Recommended
Airflow Range
CPH120***3B*** 49 60
EHK3-16 81 / 94 90 / 100 15 3500 - 4500 CFM
EHK3-30 122 / 139 125 / 150 35 3500 - 4500 CFM
EHK3-45 154 / 178 175 / 200 43 4000 - 4500 CFM
Model and
Heat Kit Usage
MCA¹ at
208 / 240V
MOP² (amps)
at 208 / 240V
Actual kW
at 240V
Recommended
Airflow Range
CPH120***3H*** 50 60
EHK3-16 82 / 95 90 / 100 15 ---
EHK3-30 122 / 140 125 / 150 35 ---
EHK3-45 155 / 179 175 / 200 43 ---
Model and
Heat Kit Usage
MCA¹
at 480V
MOP² (amps)
at 480V
Actual kW
at 480V
Recommended
Airflow Range
CPH120***4B*** 24 30
EHK4-16 46 50 15 3500 - 4500 CFM
EHK4-30 69 70 30 3500 - 4500 CFM
EHK4-45 89 90 43 4000 - 4500 CFM
Model and
Heat Kit Usage
MCA¹
at 575V
MOP² (amps)
at 575V
Actual kW
at 575V
Recommended
Airflow Range
CPH0120***7B*** 17 20
EHK7-16 36 40 15 3500 - 4500 CFM
EHK7-30 55 60 30 3500 - 4500 CFM
EHK7-45 71 80 43 4000 - 4500 CFM
¹ Minimum Circuit Ampacity
² Maximum Overcurrent Protecon device
