ProduCt SPeCifiCationS
ProduCt SPeCifiCationS
SS-CPH90-150 www.goodmanmfg.com 3
ProduCt SPeCifiCationS — 7½ tonS
CPH090
***3B***
CPH090
***4B***
CPH090
***7B***
Cooling Capacity
Total BTU/h 90,000 90,000 90,000
Sensible BTU/h 65,700 65,700 65,700
EER / IEER 11.5 / 11.2 11.5 / 11.2 11.5 / 11.2
IPLV 12.30 12.30 12.30
Decibels 83 83 83
AHRI Reference #s 3000984 3000984 3000984
Heating Capacity
BTU/h / COP (47° F) 90,000 / 3.5 90,000 / 3.5 90,000 / 3.5
BTU/h / COP (17° F) 55,500 / 2.4 55,500 / 2.4 56,500 / 2.4
Evaporator Motor / Coil
Motor Type Belt Drive Belt Drive Belt Drive
Indoor Nominal CFM 3,000 3,000 3,000
Indoor Motor FLA (Cooling) 7.8 3.9 2.5
Horsepower - RPM 2.0 - 1725 2.0 - 1725 2.0 - 1725
Piston Size (Cooling) 0.076 0.076 0.078
Filter Size 16" x 24" x 2" 16" x 24" x 2" 16" x 24" x 2"
Drain Size (NPT) ¾" ¾" ¾"
R-410A Refrigerant Charge: Cir #1 / #2 (oz.) 215 / 215 215 / 215 200 / 200
Evaporator Coil Face Area (²) 10.2 10.2 10.2
Rows Deep / Fins per Inch 4 / 16 4 / 16 4 / 16
Belt Drive Evap Fan Data
# of Wheels (D x W) 1 (15" x 12") 1 (15" x 12") 1 (15" x 12")
Motor Sheave / Blower Sheave VL40 / AK74 VL40 / AK74 VL40 / AK74
Belt AX51 AX51 AX51
Condenser Fan / Coil
Quanty of Condenser Fan Motors 2 2 2
Horsepower - RPM ¼ - 1090 ¼ - 890 ¼ - 1075
Fan Diameter / # Fan Blades 22 / 4 22 / 4 22 / 4
Outdoor Expansion Device 0.052 0.052 0.055
Outdoor Nominal CFM 7,600 7,600 7,600
Face Area (²) 32.4 32.4 32.4
# Coils / Rows Deep - Fins per Inch 2 / 2 - 20 2 / 2 - 20 2 / 2 - 20
Piston Size (Heang) 0.052 0.052 0.055
Compressor
Quanty / Type / Stage 2 / Scroll / 1 2 / Scroll / 1 2 / Scroll / 1
Compressor RLA / LRA 13.1 / 83.1 6.1 / 41.0 4.4 / 33.0
Electrical Data
Voltage / Phase / Frequency 208-230 / 3 / 60 460 / 3 / 60 575 / 3 / 60
Indoor Blower HP / FLA 1.5 / 5.0 1.5 / 2.5 2 / 2.5
Outdoor Fan HP / FLA ¼ / 1.4 ¼ / 0.8 ¼ / 0.6
Total Unit Amps 36.9 17.7 12.5
Min. Circuit Ampacity¹ 40 19 13.6
Max. Overcurrent Protecon (amps)² 50 25 15
Entrance Power Supply & Control Voltage Locang Dimple
Operating Weight (lbs) 1135 1135 1135
Ship Weight (lbs) 1175 1175 1175
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
