ProduCt SPeCifiCationS
ProduCt SPeCifiCationS
SS-CPH90-150 www.goodmanmfg.com 23
Heat kit eleCtriCal data — 12½ tonS
kW Correction Factor for 1- & 3-Phase Units
Supply Voltage 240 230 220 210 208
Correction Factor 1 0.93 0.82 0.78 0.76
kW Correction Factor for 480V Units
Supply Voltage 460 440 430
Correction Factor 0.92 0.84 0.8
For other voltage, use voltage² / 480²
kW Correction Factor for 575V Units
Supply Voltage 560 550 540
Correction Factor 0.95 0.91 0.88
Multiply rated kW by correction factor to get actual kW.
kw CorreCtion faCtorS
Model and
Heat Kit Usage
MCA¹ at
208 / 240V
MOP² (amps)
at 208 / 240V
Actual kW
at 240V
Recommended
Airflow Range
CPH150***3B*** 65 80
EHK3-16 110 110 15 4000 - 5600
EHK3-30 155 175 30 4300 - 5600
EHK3-45 194 200 43 4500 - 5600
Model and
Heat Kit Usage
MCA¹ at
208 / 240V
MOP² (amps)
at 208 / 240V
Actual kW
at 240V
Recommended
Airflow Range
CPH150***4B*** 31 40
EHK4-16 54 60 15 4000 - 5600
EHK4-30 76 80 30 4300 - 5600
EHK4-45 96 100 43 4500 - 5600
Model and
Heat Kit Usage
MCA¹ at
208 / 240V
MOP² (amps)
at 208 / 240V
Actual kW
at 240V
Recommended
Airflow Range
CPH150***7B*** 23 30
EHK7-16 42 45 15 4000 - 5600
EHK7-30 61 70 30 4300 - 5600
EHK7-45 77 80 43 4500 - 5600
¹ Minimum Circuit Ampacity (standard drive)
² Maximum Overcurrent Protecon device (standard drive)
