ProduCt SPeCifiCationS
ProduCt SPeCifiCationS
SS-CPH90-150 www.goodmanmfg.com 21
Heat kit eleCtriCal data — 8½ tonS
Model and
Heat Kit Usage
MCA¹
at 240V
MOP² (amps)
at 240V
Actual kW
at 240V
Recommended
Airflow Range
(Downshot)
Recommended
Airflow Range
(Horizontal)
CPH102***3B*** 43 50
EHK3-16 88 90 15 3400 - 3825 CFM 3400 - 3825 CFM
EHK3-30 133 150 35 3400 - 3825 CFM 3400 - 3825 CFM
EHK3-45 173 175 43 3400 - 3825 CFM 3400 - 3825 CFM
Model and
Heat Kit Usage
MCA¹
at 480V
MOP² (amps)
at 480V
Actual kW
at 480V
Recommended
Airflow Range
(Downshot)
Recommended
Airflow Range
(Horizontal)
CPH102***4B*** 20 25
EHK4-16 42 45 15 3400 - 3825 CFM 3400 - 3825 CFM
EHK4-30 65 70 30 3400 - 3825 CFM 3400 - 3825 CFM
EHK4-45 84 90 43 3400 - 3825 CFM 3400 - 3825 CFM
Model and
Heat Kit Usage
MCA¹
at 575V
MOP² (amps)
at 575V
Actual kW
at 575V
Recommended
Airflow Range
(Downshot)
Recommended
Airflow Range
(Horizontal)
CPH102***7B*** 17 20
EHK7-16 36 40 15 3400 - 3825 CFM 3400 - 3825 CFM
EHK7-30 55 60 30 3400 - 3825 CFM 3400 - 3825 CFM
EHK7-45 71 80 43 3400 - 3825 CFM 3400 - 3825 CFM
¹ Minimum Circuit Ampacity
² Maximum Overcurrent Protecon device
^ - EHK Heater Kits above require a three-phase power supply
kw CorreCtion faCtor
kW Correction Factor (for 1- & 3-Phase Units)
Supply Voltage 240 230 220 210 208
Correcon Factor 1 0.93 0.82 0.78 0.76
kW Correction Factor for 480V Units
Actual Voltage 460 440 430
Correcon Factor 0.92 0.84 0.8
For other voltage use voltage² / 480²
kW Correction Factor for 575V Units
Supply Voltage 560 550 540
Correcon Factor 0.95 0.91 0.88
Multiply rated kW by correction factor to get actual kW
minimum airflow for eleCtriC Heat
Heater Size (kW)
Min. CFM
Down-shot
Min. CFM
Horizontal
15 3,400 3,400
30 3,400 3,400
43 3,400 3,400
