ProduCt SPeCifiCationS
ProduCt SPeCifiCationS
20 www.goodmanmfg.com SS-CPH90-150
Heat kit eleCtriCal data — 7½ tonS
minimum airflow for eleCtriC Heat
Heater Size (kW) Minimum CFM
15 3,000
30 3,000
43 3,000
kW Correction Factor for 3-Phase Units
Supply Voltage 240 230 220 210 208
Correction Factor 1 0.93 0.82 0.78 0.76
kw CorreCtion faCtorS
kW Correction Factor for 575V Units
Supply Voltage 560 550 540
Correction Factor 0.95 0.91 0.88
Mulply rated kW by correcon factor to get actual kW.
kW Correction Factor for 480V Units
Supply Voltage 460 440 430
Correction Factor 0.92 0.84 0.8
For other voltage, use voltage² / 480²
Model and
Heat Kit Usage
MCA¹
at 208 / 240V
MOP² (amps)
at 208 / 240V
Actual kW
at 240V
Recommended
Airflow Range
CPH090***3B*** 40 50
EHK3-16 74 / 85 80 / 90 15 3000-3375 CFM
EHK3-30 113 / 130 120 / 150 30 3000-3375 CFM
EHK3-45 147 / 169 150 / 175 43 3000-3375 CFM
Model and
Heat Kit Usage
MCA¹
at 208 / 240V
MOP² (amps)
at 208 / 240V
Actual kW
at 240V
Recommended
Airflow Range
CPH090***4B*** 19 25
EHK4-16 42 45 15 3000-3375 CFM
EHK4-30 64 70 30 3000-3375 CFM
EHK4-45 84 90 43 3000-3375 CFM
Model and
Heat Kit Usage
MCA¹
at 208 / 240V
MOP² (amps)
at 208 / 240V
Actual kW
at 240V
Recommended
Airflow Range
CPH090***7B*** 14 15
EHK4-16 32 35 15 ---
EHK4-30 51 60 30 ---
EHK4-45 68 70 43 ---
¹ Minimum Circuit Ampacity
² Maximum Overcurrent Protection device
