4
920-198-01
A/C
Stop
Mode
Temp
Fan
Timer
O
F
/
O
C
A/C
Start
Timer
On/Off
1-4
Speed
Smart
Fan
Check
Filter
Set
Hour
Power
Cool
Money
Saver
®
PM
Fan
Only
Press to reset
13
DISPLAY
8
5
4
2
15
10
7
11
9
6
3
1
14
12
Figure 3
To start unit
1
If your air conditioner is installed and plugged into a proper re-
hcuoT.ogotydaersiti,elc at pec Power button once. The unit will
automatically be in Cool mode with the temperature set at 75°F
(24°C)andthefanspeedatF1,thesleepsetting.Thereisa3-
minute delay before the compressor will turn on. (See "Automatic
Component Protection" on this page).
2
Should theCheckFilter light turn onwhen you¿rst turn on the unit,
touch Check Filter to turn off the light. Check Filter light will come
).snoit curts nigni naelcretl¿rof7egapeeS(.esufosruoh052ret fano
Touch Check Filter to reset.
To set mode of operation
3
When you ¿rst turn on the unit, it will be inthe Cool mode(light on),
with constant fan.
4
Touch MoneySaver
®
(lighton)toactivatethe MoneySaver
®
feature.
This cycles the fan with the compressor so that the fan does not
.noit ac ¿i dim uh edsevorpmidnaygrenesevassihT.emitehtllanur
(MoneySaver
®
will also runthe fantosamplethereturn airtempera-
ture if the off cycle is too long). Or you may prefer constant fan for
more air movement. To return to constant fan, touch Cool.
5
Touch Fan Only (light on) if you want only the fan to run. You may want
to use this feature in conjunction with the FreshAir/Exhaustlever to
bring outside air into a room, or to exhaust stale air. (See page 7, "Fresh
Air and Exhaust Control" for more information.)
To adjust temperature [60°F(16°C)to90°F(32°C)]
6
COOLER–Touch andhold untilthedisplayshows thedesired
room temperature.
7
WARMER– Touch and holduntil the displayshowsthedesired
room temperature.
8
FAHRENHEIT/CELSIUS–Touch ºF/ºCtoshow the temperature
in Celsius, touch again to show Fahrenheit.
To adjust fan speed
9
Touch 1-4 Speed to see current setting. Touch again to change
deepswolsi2F,)GNITTESPEELS(gnit testsewolehtsi1F.deeps
(LOW), F3 is medium speed (MED), F4 is high speed (HIGH).
To activate smart fan
10
Touch Smart Fan (light on). Smart Fan will adjust the fan speed
,elpmaxeroF.leveltrofmocderisedehtniatniamotyl lac i tam ot ua
do ir epdednetxenarofnepoeraemohruoynisroodedistuoehtfi
of time, or more people enter a room, Smart Fan may adjust to a
higher fan speed to compensate for the increased heat load. This
keeps you from having to adjust the fan speed on your own. Smart
Fan cannot be activated in the Fan Only mode.
To deactivate smart fan
11
Touch 1-4 Speed, and select your desired fan speed.
To set hour clock
12
Press Set Hour once to see the current clock setting. Continue
pressing the button until thehour closestto theactual timeappears
in the display.
MAKE SURE YOU SET A.M. AND P.M. PROPERLY. Alight will appear in
the upper left corner of the display when the hour is P.M.
NOTE: Minutes will NOT show on display.
To set the timer
NOTE: .snoitcnufremittesotgni tpmet taerofebkcolcruoHteS
YoucansettheA/C Start and A/C Stop ruohenofomum i nimaremit
apart and a maximum of 23 hours apart.
13
TIMER STOP -PresstheA/C Stop button and continue pressing
until the hour you want the unit to shut off appears in the display
(A.M. or P.M.). The stop time for cooling will then be set.
14
START TIME - Press A/C Start to view the current start time for
cooling. Continue pressing until the hour you want the unit to start
appears in the display (A.M. or P.M.). The start time for cooling will
then be set.
15
Press theTimerOn/ Off button onceto activate(light on) thetimer
functio
n. Touch Timer On/ Off again (light off) to cancel the timer
-esneebevahsemitffodnanoehtecnO.eris edosuoyfinoitcnuf
lected, they will remain in memory, and cycle daily until changed.
NOTE: eht,de tpur ret nisirewopr
odeggulpnusitinufI Set Hour button
ehtrotes erebtsum Timer On/ Off functions will not work.
Automatic component protection
.noitcetorPtnen op moCcitamotuAhtiwdeppiuqesitinuruoY
Toprotectthe c
ompressoroftheunit,thereis athree minutetime delayifyou
turn the unit off or if power is interrupted. The fan will not be affected.
How to operate your Friedrich room air conditioner (QuietMaster Programmable)
