Z-Wave® Alternate Programming
Example with HA-09WD (continued)
4. On the HA-09WD Remote Control,
simultaneously press and hold the ON and OFF
buttons of the desired SCENE. Both red and
green LEDs will flash. (Note: The LEDs will time
out after 10 seconds. If this happens, this step
needs to be repeated). Release the ON and
OFF buttons.
5. While holding the INCLUDE button on
the controller, press and hold for 4 seconds
the BIND button on the Z-Wave
® Enabled
Thermostat, then release. The green LED on
the controller will flash.
6. Thermostat programming to the Controller
is now complete.
OPERATING THERMOSTAT:
1. Place the thermostat in either the HEAT
or COOL mode by manually pressing the
appropriate button.
2. Press the controller SCENE button ON
for NORMAL target temperature and the
SCENE button OFF for SAVE ENERGY target
temperature.
REMOVING THERMOSTAT FROM PRIMARY
CONTROLLER:
Remove the thermostat from the primary
controller as you would remove any Z-Wave
®
module. Use the BIND button the same as the
PROGRAM button, to activate the Z-Wave
®
signal. See the controller User Manual for
specific instructions.
ON OFF
1
2
3
4
5
6
DELETE
INCLUDE
4
AUTO
ON
FAN
HEAT
COOL
SAVE
ENERGY
NORMAL
RESET
COOL
3
Programming Examples
4 Seconds
4
5A
AUTO
ON
FAN
HEAT
COOL
SAVE
ENERGY
NORMAL
RESET
COOL
5B
33
