NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
DETAILED INSTALLATION STEPS
The appliance is shipped with all gas controls
and components installed and pre-wired.
1. Remove the shipping carton. Remove the
shipping pad, exposing the front glass
door.
2. Remove the bottom louvered control panel
per instructions on Page 26 (see Control
Compartment Access / Louver Panel Instruc-
tions).
3. Open the two latches (located under the fire-
box floor) securing the glass door. Remove
the door by tilting it outward at the bottom
and lifting it up. Set the door aside protecting
it from inadvertent damage. See Figure 55
on Page 30.
4. Remove the top louvered panel and locate
the pressure relief plates.
5. Lift the pressure relief plates and remove
the cardboard from beneath each plate (be
careful not to damage the white gasket).
See Figure 10.
Figure 10
REMOVE
CARDBOARD
BEFORE USING
REMOVE
CARDBOARD
BEFORE USING
Pressure Relief Plates
Remove Cardboard Before
Using Appliance
TYPICAL INSTALLATION SEQUENCE
The typical sequence of installation is outlined
below. However, each installation is unique
and may result in variations to the steps
described.
See the page numbers references in the follow-
ing steps for detailed procedures.
Step 1. (Page 9) Construct the appliance
framing. Position the appliance within
the framing and secure with nailing
brackets.
Step 2. (Page 11) Route gas supply line to
appliance location.
Step 3. (Page 12) Install the vent system and
exterior termination.
Step 4. (Page 25) Field Wiring
Install the operating control switch (not
factory provided) and bring in electri-
cal service line for forced air-circulat-
ing blower (standard equipment).
Step 5. (Page 26) Make connection to gas
supply.
Step 6. (Page 27) Verify appliance opera-
tion.
Step 7. (Page 28) Install the logs, decorative
volcanic stone and glowing embers.
Step 8. (Page 30) Install glass door assem-
bly.
Step 9. (Page 30) Adjust burner primary air
shutter to achieve proper flame ap-
pearance.
Step 10. (Page 31) Install the hoods.
Step 11. (Page 32) Attach Safety in Operation
Warnings.
Note: Frame the opening to the exact dimensions
specified in the framing details of this manual.
Side
Framing
Unit Nailing Flange
(No clearance to
combustible
framing is required)
Left Side Front Corner of Fireplace Shown
(Right Side Requirements the Same)
Unit Being Secured By Its Nailing Flanges
To The Framing
Figure 11
Step 1. FRAMING
Frame these appliances as illustrated in Figures
12 and 13 on Pages 10 and 11 (Figure 13
applies to corner framing installations only).
All framing details must allow for a minimum
clearance to combustible framing members as
shown in Table 5 on Page 8.
If the appliance is to be elevated above floor
level, a solid continuous platform must be
constructed below the appliance.
Headers may be in direct contact with the
appliance top spacers but must not be sup-
ported by them or notched to fit around them.
All construction above the appliance must be
self-supporting. DO NOT use the appliance for
structural support.
The fireplace should be secured to the side framing
members using the unit's nailing flanges - one top
and bottom on each side of the fireplace front. See
Figure 11. Use 8d nails or their equivalent.
WARNING
Failure to position the parts in
accordance with these diagrams
or failure to use only parts specifi-
cally approved with this appliance
may result in property damage or
personal injury.
AVERTISSEMENT
Risque de dommages ou de
blessures si les pièces ne sont
pas installées conformément à
ces schémas et ou si des pièces
autres que celles spécifiquement
approuvées avec cet appareil sont
utilisées.
