Inserting the bobbin
1Place the bobbin in the bobbin holder with the
thread running off counterclockwise.
1 Thread
2 Bobbin Holder
2 Guide the thread into notch (A) on the front
of the bobbin holder.
3Draw the thread to the left, sliding it between the
tension spring blades.
4Continue to draw the thread lightly until the
thread slips into side notch (B). The bobbin
should turn counterclockwise when pulling the
bobbin thread. If not, reverse the bobbin and
re-thread.
5 Pull out about 10 cm (4") of thread to the rear.
Refer to the threading chart shown on the hook
cover plate.
Reattach the hook cover plate.
3 Threading Chart
5
3
1
2
(A)
2
3
(B)
4
(B)
1
