prodUCt speCifiCations
prodUCt speCifiCations
SS-CPC36-72 www.goodmanmfg.com 5
p
rodUCt
s
peCifiCations
— CpC060 B m
odels
CPC060
XXX1DXXX
CPC060
XXX3DXXX
CPC060
XXX3BXXX
CPC060
XXX4BXXX
CPC060
XXX7BXXX
Total BTU/h 59,500 59,500 59,500 59,500 59,500
Sensible BTU/h 43,200 43,200 43,200 43,200 43,200
SEER / EER 13 / 11.3 13 / 11.3 13 / 11.3 13 / 11.3 13 / 11.3
Decibels 78 78 78 78 78
ARI Reference #s
4385056 4385057 4385057 4385058 4397606
Motor Type Direct Direct Belt Belt Belt
Indoor Nominal CFM 2,000 2,000 2,000 2,000 2,000
Expansion Device Piston Piston Piston Piston Piston
Piston Size (Cooling) 0.086 0.086 0.086 0.086 0.082
Filter Size (") (4) 14 x 20 x 2 (4) 14 x 20 x 2 (4) 14 x 20 x 2 (4) 14 x 20 x 2 (4) 14 x 20 x 2
Drain Size (NPT) ¾" ¾" ¾" ¾" ¾"
R-410A Refrigerant Charge (oz.) 162 162 162 162 162
Face Area (²) 7.8 7.8 7.8 7.8 7.8
Rows Deep/ Fins per Inch 4 / 16 4 / 16 4 / 16 4 / 16 4 / 16
Tube Diameter - Material 5/16 - Copper 5/16 - Copper 5/16 - Copper 5/16 - Copper 5/16 - Copper
Standard Direct Drive (D x W) HP (11" X 10") 1 (11" X 10") 1 --- --- ---
Standard Belt Drive (D x W) HP --- --- (11" X 10") 1 (11" X 10") 1 (11" X 10") 1½
High-Stac Belt Drive (D x W) HP --- --- (11" X 10") 1½ (11" X 10") 1½ (11" X 10") 1½
# of Wheels (D x W) --- --- 1 (11" x 10") 1 (11" x 10") 1 (11" x 10")
Motor Sheave --- --- VL44 x ⅝ VL44 x ⅝ VL44 x ⅝
Blower Sheave / Belt --- --- AK61x1 / AX53 AK61x1 / AX53 AK61x1 / AX53
Horsepower / RPM ¼ / 1,090 ¼ / 1,090 ¼ / 1,090 ¼ / 1,090 ¼ / 1,075
Fan Diameter/ # Fan Blades 22 / 4 22 / 4 22 / 4 22 / 4 22 / 4
Outdoor Nominal CFM 3,800 3,800 3,800 3,800 3,800
Face Area (²) 17.0 17.0 17.0 17.0 17.0
Rows Deep/ Fins per Inch 2 / 18 2 / 18 2 / 18 2 / 18 2 / 18
Tube Diameter - Material 5/16 - Copper 5/16 - Copper 5/16 - Copper 5/16 - Copper 5/16 - Copper
Quanty / Type 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll
Stage Single Single Single Single Single
Compressor RLA / LRA 26.4 / 134 16 / 110 16 / 110 7.8 / 52 5.7 / 38.9
Voltage-Phase-Frequency 208/230-1-60 208/230-3-60 208/230-3-60 460-3-60 575-3-60
Indoor Blower HP / FLA 1.0 / 7.6 1.0 / 7.6 1.0 / 3.8 1.0 / 1.9 1.5 / 2.3
Indoor Blower LRA 24 ---- 24 12 12
Outdoor Fan HP / FLA ¼ / 1.40 ¼ / 1.40 ¼ / 1.40 ¼ / 0.80 ¼ / 0.60
Min. Circuit Ampacity¹ 42 29 25 12 10
Max. Overcurrent Protecon² 60 amps 45 amps 40 amps 20 amps 15 amps
Power Supply Conduit Hole 1.125" 1.125" 1.125" 1.125" 1.125"
Low-Voltage Conduit Hole ½" ½" ½" ½" ½"
580 580 580 580 580
605 605 605 605 605
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
