prodUCt speCifiCations
prodUCt speCifiCations
SS-CPC36-72 www.goodmanmfg.com 27
Unit ClearanCes
Maintainanadequateclearancearoundtheunitforsafety,service,
maintenance,andproperunitoperation.Leaveatotalclearance
of75”onthemaincontrolpanelsideoftheunitforpossible
removaloffanshaft,coil,electricheat,andgasfurnace.
Leaveaclearanceof48”onallothersidesoftheunitfor
possiblecompressorremovalorserviceaccess,and
toensureproperventilationandcondenser
airow.Donotinstalltheunit
Beneathanyobstruction.Install
theunitawayfromallbuilding
exhauststoinhibitingestionof
exhaustairintotheunit’sfresh-air
intake.
eleCtriCal entranCe loCations
3½” Dia.
47½”
7½”
Power Thru
the Curb
30¼”
12⅜”
Low-Voltage Entrance
(Remove Plug)
High-Voltage Entrance
