prodUCt speCifiCations
prodUCt speCifiCations
18 www.goodmanmfg.com SS-CPC36-72
expanded Cooling data — CpC036

° ° ° ° ° °

   63 67 71  63 67 71  63 67 71  63 67 71  63 67 71  63 67 71
70
1350
MBh 33.9 35.1 38.5 - 33.1 34.3 37.6 - 32.3 33.5 36.7 - 31.5 32.7 35.8 - 30.0 31.1 34.0 - 27.8 28.8 31.5 -
S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
∆T 17 14 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
kW 2.44 2.48 2.56 - 2.61 2.66 2.74 - 2.76 2.82 2.90 - 2.90 2.95 3.05 - 3.01 3.07 3.17 - 3.11 3.17 3.27 -
Amps 8.5 8.7 8.9 - 9.0 9.2 9.4 - 9.6 9.8 10.0 - 10.1 10.3 10.5 - 10.6 10.8 11.0 - 11.1 11.3 11.6 -
HIPR 221 237 251 - 247 266 281 - 281 303 320 - 321 345 364 - 361 388 410 - 398 429 453 -
LOPR 107 114 124 - 113 120 131 - 118 125 137 - 124 131 144 - 130 138 150 - 134 143 156 -
1200
MBh 32.9 34.1 37.4 - 32.2 33.3 36.5 - 31.4 32.5 35.6 - 30.6 31.7 34.8 - 29.1 30.2 33.0 - 26.9 27.9 30.6 -
S/T 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.79 0.66 0.45 - 0.79 0.66 0.46 -
∆T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 11 - 16 14 11 -
kW 2.42 2.47 2.54 - 2.59 2.64 2.72 - 2.74 2.80 2.88 - 2.87 2.93 3.02 - 2.99 3.05 3.14 - 3.08 3.15 3.25 -
Amps 8.5 8.6 8.8 - 8.9 9.1 9.3 - 9.5 9.7 9.9 - 10.0 10.2 10.4 - 10.5 10.7 11.0 - 11.0 11.2 11.5 -
HIPR 218 235 248 - 245 264 278 - 279 300 317 - 317 342 361 - 357 384 406 - 394 425 448 -
LOPR 106 113 123 - 112 119 130 - 116 124 135 - 122 130 142 - 128 136 149 - 133 141 154 -
1050
MBh 30.4 31.5 34.5 - 29.7 30.8 33.7 - 29.0 30.0 32.9 - 28.3 29.3 32.1 - 26.9 27.8 30.5 - 24.9 25.8 28.2 -
S/T 0.67 0.56 0.38 - 0.69 0.58 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.76 0.64 0.44 -
∆T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 15 12 - 17 14 11 -
kW 2.37 2.41 2.48 - 2.53 2.58 2.66 - 2.68 2.73 2.81 - 2.81 2.86 2.95 - 2.92 2.98 3.07 - 3.01 3.07 3.17 -
Amps 8.3 8.4 8.6 - 8.8 8.9 9.1 - 9.3 9.5 9.7 - 9.8 10.0 10.2 - 10.3 10.5 10.7 - 10.7 10.9 11.2 -
HI
PR 212 228 241 - 238 256 270 - 270 291 307 - 308 331 350 - 346 373 394 - 383 412 435 -
LOPR 103 109 120 - 109 116 126 - 113 120 131 - 119 126 138 - 124 132 144 - 129 137 149 -
75
1350
MBh 34.5 35.5 38.4 41.2 33.7 34.7 37.5 40.3 32.9 33.8 36.6 39.3 32.1 33.0 35.7 38.4 30.5 31.4 34.0 36.4 28.2 29.1 31.5 33.8
S/T 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.94 0.84 0.63 0.41 0.94 0.84 0.64 0.41
∆T 19 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 19 18 15 10 18 17 14 9
kW 2.46 2.50 2.58 2.65 2.63 2.68 2.76 2.85 2.78 2.84 2.93 3.02 2.92 2.98 3.07 3.17 3.03 3.10 3.19 3.29 3.13 3.20 3.30 3.40
Amps 8.6 8.7 8.9 9.2 9.1 9.2 9.5 9.7 9.6 9.8 10.1 10.4 10.1 10.3 10.6 10.9 10.6 10.8 11.1 11.5 11.1 11.4 11.7 12.0
HIPR 223 240 253 264 250 269 284 296 284 306 323 337 324 348 368 384 364 392 414 432 402 433 457 477
LOPR 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
1200
MBh 33.5 34.5 37.3 40.0 32.7 33.7 36.4 39.1 31.9 32.9 35.6 38.2 31.1

34.7 37.2 29.6 30.5 33.0 35.4 27.4 28.2 30.5 32.8
S/T 0.78 0.70 0.53 0.34 0.81 0.73 0.55 0.35 0.83 0.75 0.56 0.36 0.86

0.58 0.37 0.89 0.80 0.60 0.39 0.90
0.81 0.61 0.39
∆T 20 19 15 10 20 19 15 11 20 19 15 11 21
19
15 11 20 19 15 11 19 17 14 10
kW 2.44 2.49 2.56 2.63 2.61 2.66 2.74 2.82 2.76 2.82 2.90 2.99 2.90

3.05 3.14 3.01 3.07 3.17 3.27 3.11 3.17 3.27 3.38
Amps 8.5 8.7 8.9 9.1 9.0 9.2 9.4 9.6 9.6 9.8 10.0 10.3 10.1

10.5 10.8 10.6 10.8 11.1 11.4 11.1 11.3 11.6 11.9
HI
PR 221 237 251 261 248 266 281 293 281 303 320 334 321

364 380 361 388 410 427 399 429 453 472
LOPR 107 114 124 133 113 120 131 140 118 125 137 146 124
131
144 153 130 138 150 160 134 143 156 166
1050
MBh 30.9 31.8 34.4 37.0 30.2 31.1 33.6 36.1 29.5 30.3 32.8 35.2 28.7 29.6 32.0 34.4 27.3 28.1 30.4 32.7 25.3 26.0 28.2 30.3
S/T 0.76 0.68 0.51 0.33 0.78 0.70 0.53 0.34 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.87 0.78 0.59 0.38
∆T 20 19 15 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10
kW 2.38 2.43 2.50 2.57 2.55 2.60 2.68 2.76 2.70 2.75 2.84 2.92 2.83 2.89 2.97 3.07 2.94 3.00 3.09 3.19 3.03 3.10 3.19 3.30
Amps 8.3 8.5 8.7 8.9 8.8 9.0 9.2 9.5 9.4 9.5 9.8 10.1 9.9 10.0 10.3 10.6 10.3 10.5 10.8 11.1 10.8 11.0 11.3 11.7
HIPR 214 230 243 254 240 258 273 285 273 294 310 324 311 335 353 369 350 376 398 415 387 416 439 458
LOPR 104 111 121 129 110 117 128 136 114 121 133 141 120 128 139 148 126 134 146 155 130 138 151 161
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service ports. Amps:Unitamps(comp.+evaporator+condenserfanmotors)
