Commercial Lighting Design Guide infiNET Wireless Technology
Doc. 4775A 76
infiNET Dimmers, Switches, and Thermostat
Model Load Function
CLW-DIM1RF
infiNET Wall Box
Dimmer
1000-watt
wall mount
dimmer
The single large rocker button provides access to three user presets. With each
selection, the lighting levels fade naturally between each preset level. Pressing
and holding the rocker button up or down allows manual adjustment of the lighting
level.
CLW-DIM4RF
infiNET Wall Box
Dimmer and
Keypad
1000-watt
wall mount
dimmer and
programmable
keypad
All four pushbuttons are software programmable for any Crestron system function,
enabling control over additional lighting circuits, fans, drapes, audio levels, etc.
CLW-DIMS1RF
infiNET Wall Box
Master Dimmer
1000-Watt
wall mount
dimmer
Multipoint dimming is enabled using one CLW-DIMS1RF master dimmer along
with one or more CLW-SLVD1RF slave dimmers. Multipoint dimming is similar
to conventional 3-way or 4-way switching, allowing dimming control of a single
load from multiple locations in the room.
CLW DIMS4RF
infiNET Wall Box
Master Dimmer
and Keypad
1000-watt
wall mount
dimmer and
programmable
keypad
Multi-point dimming is enabled using one CLW-DIMS4RF master dimmer along
with one or more CLW-SLVD1RF slave dimmers. Multipoint dimming is similar
to conventional 3-way or 4-way switching, allowing dimming control of a single
load from multiple locations in the room. All four pushbuttons are software
programmable for any Crestron system function, enabling control over additional
lighting circuits, fans, drapes, audio levels, etc.
CLW-SLVD1RF
infiNET Wall Box
Slave Dimmer
1000-watt
wall mount
slave dimmer
Slave dimmer designed for use with the CLW-DIMS1RF and CLW-DIMS4RF infiNET
master dimmers.
CLW-SW1RF
infiNET Wall Box
Switch
1000-watt
wall mount
switch
The single large rocker button provides simple on/off operation to control a range of
lighting or fan loads. An adjustable turn-off delay allows the user time to exit the
room before the lights shut off.
CLW-SWS1RF
infiNET Wall Box
Master Switch
1000-watt
wall mount
switch
Multi-point switching is enabled using one CLW-SWS1RF master switch along with
one or more CLW-SLVS1RF slave switches. Multipoint switching is similar to
conventional 3-way or 4-way switching, allowing control of a single load from
multiple locations in the room.
CLW-SW4RF
infiNET Wall Box
Switch and
Keypad
1000-watt
wall mount
switch and
programmable
keypad
An adjustable turn-off delay allows the user time to exit the room before the lights
shut off. All four pushbuttons are software programmable for any Crestron system
function, enabling control of additional lighting circuits, fans, drapes, audio levels,
etc.
CLW-SWS4RF
infiNET Wall Box
Master Switch
and Keypad
1000-watt
wall mount
switch and
programmable
keypad
All four pushbuttons are software programmable for any Crestron system function,
enabling control of additional lighting circuits, fans, drapes, audio levels, etc. Multi-
point switching is enabled using one CLW-SWS4RF master switch along with one
or more CLW-SLVS1RF slave switches. Multipoint switching is similar to
conventional 3-way or 4-way switching, allowing control of a single load from
multiple locations in the room.
CLW-SLVS1RF
infiNET Wall Box
Slave Switch
1000-watt
wall mount
slave switch
Slave switch designed for use with the CLW-SWS1RF and CLW-SWS4RF infiNET
master dimmers.
CLF-DIMRFB
infiNET Lamp
Dimmer
500 watts V/A
Dimmer
Freestanding dimmer module designed to sit on the floor to provide dimming
control of a conventional floor lamp or table lamp. It enables local dimming control
via a built-in footswitch, and remote control via infiNET.
HTT-B10X
infiNET Table
Top Controller
The HTT-B10X is a simple, convenient wireless controller. Two-way infiNET wireless operation supports
true-feedback. A clean array of 10 backlit pushbuttons with individual feedback LEDs affords easy,
tactile control of any custom function. The HTT-B10X is a fully-programmable controller designed to
operate as part of a complete Crestron automation system, communicating via the infiNET wireless
control network.
CHV-TSTATRF
Wireless
Networked
Thermostat
The CHV-TSTATRF is designed for heating and cooling control of baseboard, forced air, heat pump, and
dual-fuel heat pump HVAC systems. The large backlit LCD display provides a clear view of current
temperature, setpoint, system mode, fan status, and setup functions. Climate control features include
separate heating and cooling setpoints, and adjustable anticipators to prevent overshooting the desired
temperature. Continuous fan operation can be selected when needed for increased circulation.
