Crestron Commercial Lighting Design Guide DIN Rail Products
Doc 4775A 53
DIN-AO8
The DIN-AO8 is a DIN Rail-mounted automation control module that provides
eight analog output ports for interfacing with third-party lighting and
heating/cooling systems.
Analog Outputs
Each analog output port provides a 0 to 10 volt DC control signal ideally suited
for controlling 0-10V lighting dimmers and heating/cooling valves. 10-bit
resolution ensures precise recall of lighting and climate control settings and
smooth ramping between levels.
Features
Eight 0-10V analog output control ports (Maximum sink current
20mA per channel)
Interface for 3rd-party lighting and heating/cooling
Fully programmable functionality via DIN-AP2 Setup via front panel
or software
DIN-IO8
The DIN-IO8 is a DIN Rail-mounted automation control module that provides
eight Versiport I/O ports for interfacing with a wide range of third-party devices
and systems. Each Versiport can be configured via software to function as
a digital or analog sensing input or as a digital trigger output.
Features
8 Versiport I/O ports
Interface for 3rd-party sensors, detectors, contact closures,
and alarms
Fully programmable functionality via DIN-AP2
Versiports
Configured as a digital input, the Versiport senses a contact closure or logic
level signal from devices such as motion detectors, partition sensors, alarm
panels, 12V triggers, and all types of switches and relays. As an analog input,
the Versiport can sense changes in a resistance or DC voltage level, working
with everything from temperature and light sensors to water level meters to
volume control potentiometers. As a digital output, the Versiport provides
a logic level closure signal to trigger control and alarm inputs on a variety
of external devices.
