9NetworkAIR ACPA4000
Install the adapter in a drop ceiling
Use the ceiling adapter to provide an intake and exhaust outlet for the condenser.
Note: Allow at least 305 mm (12 in) of open space above the ceiling adapter opening so
exhaust air is not blocked.
1. Determine a location to install the ceiling adapter.
2. Remove the ceiling tile in the chosen location and
save it for a future step.
3. Place the ceiling adapter into the ceiling tile grid.
4. Secure the ceiling adapter to the building structural
support (not the drop ceiling), using 10-gauge (minimum) steel wire.
5. When using 2 x 4 ft ceiling tiles, insert a cross
member (not provided) for added support.
na0373a
na0397a
na0394a
